| B84/3 |
Backup camera |
4L |
| B84/3 |
Backup camera |
12L |
| H3/4 |
Backup warning horn |
16L |
| N87/6 |
Radio/radio with navigation NG |
4A |
| N87/6 |
Radio/radio with navigation NG |
12A |
| U72 |
Valid for all except USA, Canada |
2A |
| W29/8 |
Left D-pillar ground point |
5F |
| W52/7 |
Left rear crossmember ground point |
17L |
| W71/1 |
Driver seat frame ground point 1 |
22G |
| X169 |
Backup camera connector |
11J |
| X169/1 |
COC/DLS backup camera connector |
3F |
| X169/2 |
COC/HLS backup camera connector |
1F |
| X169/3 |
Body manufacturer backup camera connector 1 |
20L |
| X169/4 |
Body manufacturer backup camera connector 2 |
2L |
| X169/6 |
Backup camera connector |
3H |
| X169/7 |
Backup camera connector |
18G |
| X18/51 |
COC/roof connector 2 |
7G |
| X18/52 |
HLS/roof connector |
14G |
| X18/54 |
HLS/roof connector 3 |
13G |
| X18/76 |
COC/roof connector 6 |
7G |
| Z28/84 |
Radio additional fan connector sleeve |
15D |
| Z3/69 |
Tml. 15 connector sleeve |
12G |
| Z38 |
Backup lamp connector sleeve |
15L |
| Z38/2 |
Backup lamp connector sleeve |
17G |
| Z87/39 |
Backup camera microphone connector sleeve |
13D |
| Z87/40 |
Backup camera microphone connector sleeve |
5J |
| Z87/42 |
Backup camera microphone connector sleeve |
11D |
