| A0 |
Color code key |
72L |
| Code BR9 |
|
35E |
| Code CV1 |
Winter service vehicle preinstallation |
33E |
| Code E28 |
Additional battery for retrofitted consumers |
23D |
| Code E36 |
Cutoff relay with additional battery |
37E |
| Code E36 |
Cutoff relay with additional battery |
35E |
| Code EV3 |
|
31E |
| Code HH2 |
Electric auxiliary air heater |
45E |
| Code M46 |
Alternator 14 V/220 A |
54E |
| Code M60 |
Alternator 14 V/250 A |
54E |
| Code MS0 |
Radiator fan, electric |
52E |
| Code P57 |
|
28E |
| Code ZU7 |
Canada national version |
2G |
| Code ZU8 |
USA national version |
2H |
| F55/7 |
Fuse block 7 (9-pin) |
16L |
| F55/7f4 |
Backup battery charging current fuse 40 |
15K |
| F55/7f5 |
Backup battery reference voltage SAM fuse 41 |
16K |
| F59 |
Fuse box |
46L |
| F59 |
Fuse box |
63L |
| F59/7 |
Fuse box |
4A |
| F59/7 |
Fuse box |
12A |
| F59/7 |
Fuse box |
36A |
| F59/7 |
Fuse box |
20A |
| F59/7 |
Fuse box |
28A |
| F59/7.10 |
Snowplow/cargo liftgate/dumper vehicle hydraulic pump fuse |
31B |
| F59/7.2 |
Fuse, circuit 30 SAM/fuse and relay module |
3B |
| F59/7.4 |
Backup battery fuse |
6B |
| F59/7.5 |
Fuse, ci reu it 30 |
20B |
| F59/7.8 |
Retarder fuse |
36B |
| F59/7.9 |
Additional battery fuse |
38B |
| F59/8 |
Fuse box |
44A |
| F59/8 |
Fuse box |
52A |
| F59/8 |
Fuse box |
60A |
| F59/8.13 |
Fuse, circuit 30 PTC heater booster |
46B |
| F59/8.14 |
Fuse, circuit 30 air conditioning additional fan |
51B |
| F59/8.16 |
Retarder/battery cutoff relay fuse |
40B |
| F59/8.18 |
Alternator fuse |
55B |
| G1/12 |
On-board electrical system backup battery |
9L |
| G1/9 |
Additional battery RHD |
26L |
| G2/7 |
Alternator with LIN bus |
58L |
| K120 |
On-board electrical system backup battery relay |
8L |
| K40/9 |
Fuse and relay module |
5L |
| K40/9f3 |
Circuit 30z gasoline engine fuse, electronic ignition lock, instrument cluster |
3L |
| K57 |
Battery cutoff relay |
39L |
| K57/4 |
Battery cutoff relay RHD |
39L |
| K9/2 |
Additional fan relay (mono) |
49L |
| M91 |
Electric fan |
53L |
| N10 |
SAM control unit |
13L |
| N10 |
SAM control unit |
43L |
| N10 |
SAM control unit |
61L |
| U1 |
Valid for left-hand drive vehicles |
23E |
| U1 |
Valid for left-hand drive vehicles |
37E |
| U2 |
Valid for right-hand drive vehicles |
25E |
| U2 |
Valid for right-hand drive vehicles |
37F |
| U67 |
Va Ii d for AC mono fan |
48H |
| U68 |
Val id for AC duo fan |
50H |
| U72 |
Valid for all except USA, Canada |
2H |
| V19 |
ECO start/stop function diode |
61A |
| W10/13 |
Additional battery ground point RHD |
27L |
| W2 |
Right front lamp unit ground point |
54H |
| W52/7 |
Left rear crossmember ground point |
29H |
| W52/8 |
Right rear crossmember ground point |
31H |
| W52/8 |
Right rear crossmember ground point |
33H |
| W71/1 |
Driver seat frame ground point 1 |
41L |
| W71/3 |
Driver seat frame ground point 3 |
11L |
| W71/3 |
Driver seat frame ground point 3 |
61E |
| X167/1 |
Circuit 30 dumper vehicle electrical connector |
30L |
| X167/2 |
Circuit 31 dumper vehicle electrical connector |
29L |
| X168/1 |
Circuit 30 cargo liftgate electrical connector |
32L |
| X168/3 |
Circuit 31 cargo liftgate electrical connector |
31L |
| X173 |
Circuit 30 retarder electrical connector |
36L |
| X211 |
Hydraulic pump preinstallation electrical connector |
34L |
| X211/1 |
Hydraulic pump preinstallation electrical connector |
33L |
| X4/53 |
Additional battery terminal 30 battery clamp |
24L |
| X5/6 |
Electrical connector |
56L |
| X64/13 |
Double auxiliary fan electrical connector |
49G |
| Z26/1 |
Circuit D+ connector sleeve |
44G |
| Z5/4 |
A/C fan circuit 30 connector sleeve |
50L |
| Z7/74 |
Tml. 30 connector sleeve |
20L |
| Z7/75 |
Tml. 30 connector sleeve |
21L |
