| A2 105 |
Keyless Entry load compartment antenna 1 |
51L |
| A2/106 |
Keyless Entry load compartment antenna 2 |
52L |
| A2/112 |
Keyless Entry right side wall antenna |
48L |
| A2/113 |
Keyless Entry left side wall antenna |
50L |
| A2/114 |
Keyless Entry load compartment antenna 3 |
52L |
| A46 |
Tone signal generator |
12A |
| B84/3 |
Backup camera |
45L |
| E22/6 |
Left roof additional turn signal lamp |
8L |
| E22/7 |
Right roof additional turn signal lamp |
10L |
| E42/3 |
Blue left front rotating beacon |
11L |
| E42/4 |
Blue right front rotating beacon |
13L |
| E45/1 |
Left rear fog lamp |
59L |
| E45/2 |
Right rear fog lamp |
61L |
| F55/3 |
Fuse block (9 fuses) |
15A |
| F55/3f2 |
Fuse 2 (30 A), rear wiper |
14B |
| F55/5 |
Fuse block (9 fuses) |
18A |
| F55/5f1 |
Fuse 19 (5/25 A), OCP [DBE]/tilting/sliding roof |
16B |
| F55/5f5 |
Fuse 23 (10/15 A) electrical components, other make body/left rear socket |
19B |
| F55/5f7 |
Fuse 25 (15 A), right rear socket |
21B |
| H3/1 |
Battery-operated horn |
26A |
| H3/4 |
Backup warning horn |
46A |
| K13/5 |
Heated rear window relay 1 |
2A |
| K13/6 |
Heated rear window with EDW relay 2 |
5A |
| K93 |
Illumination relay |
24A |
| M14/7 |
Rear-end door ZV actuator |
29L |
| N10 |
SAM control unit |
23L |
| N10 |
SAM control unit |
55L |
| N33/6 |
Hot air auxiliary heating control unit |
35A |
| N33/6 |
Hot air auxiliary heating control unit |
39A |
| N34 |
Heater timer |
36L |
| N34 |
Heater timer |
42L |
| N69/5 |
Keyless Entry control unit |
50A |
| N70 |
DBE control unit |
17L |
| N70 |
DBE control unit |
27L |
| N9/1 |
Additional turn signal module |
9A |
| N9/1 |
Additional turn signal module |
55A |
| R1/1 |
Left heated rear window |
3L |
| R1/2 |
Right heated rear window |
6L |
| S62/41 |
Engine hood switch |
27A |
| U1 |
Valid for left-hand drive vehicles |
60F |
| U2 |
Valid for right-hand drive vehicles |
58F |
| U3 |
Valid for vehicles with all-wheel drive |
58F |
| U3 |
Valid for vehicles with all-wheel drive |
60F |
| U32 |
Val id for MPV version |
53H |
| U6 |
Valid for auxiliary heater (warm air), AIRTRONIC D2 |
33B |
| U7 |
Valid for auxiliary heater (warm air), AIRTRONIC D4 |
37B |
| U72 |
Valid for all except USA, Canada |
7A |
| U72 |
Valid for all except USA, Canada |
33A |
| U72 |
Valid for all except USA, Canada |
48A |
| W29/8 |
Left D-pillar ground point |
8H |
| W29/8 |
Left D-pillar ground point |
20H |
| W38 |
Roof ground point |
12H |
| W52/7 |
Left rear crossmember ground point |
59G |
| W52/7 |
Left rear crossmember ground point |
61G |
| W52/7 |
Left rear crossmember ground point |
47A |
| W71/2 |
Driver seat frame ground point 2 |
22A |
| W9/6 |
Left front lamp unit ground point |
28D |
| X169 |
Backup camera connector |
44H |
| X178 |
Front roof connector |
43L |
| X18/52 |
HLS/roof connector |
26E |
| X18/53 |
HLS/roof connector 2 |
1E |
| X19/6 |
Left heated rear window connector |
3H |
| X19/7 |
Right heated rear window connector |
5H |
| X49/11 |
Left rear fog lamp connector |
58H |
| X49/12 |
Right rear fog lamp connector |
60H |
| X58/15 |
Load compartment socket |
21L |
| X58/4 |
Load compartment socket |
20L |
| X72 |
Stationary heater connector |
36D |
| X72/10 |
Stationary heater connector |
34D |
| X72/11 |
Stationary heater connector |
38D |
| X8/20 |
Right roof/rear-end door connector |
31H |
| X8/21 |
Right roof/rear-end door connector |
4J |
| X8/23 |
Left roof/rear-end door connector |
1J |
| Z21/16 |
CL [ZV] control circuit 1 connector sleeve |
32A |
| Z21/17 |
CL [ZV] control circuit 1 connector sleeve |
31A |
| Z3/59 |
Rear-end door wiper motor tml. 15 connector sleeve |
15L |
| Z3/69 |
Tml. 15 connector sleeve |
42A |
| Z3/69 |
Tml. 15 connector sleeve |
44A |
| Z30/11 |
Left turn signal indicator connector sleeve |
54G |
| Z30/12 |
Right turn signal indicator connector sleeve |
56G |
| Z38 |
Backup lamp connector sleeve |
45F |
| Z43 |
Heated rear window connector sleeve |
1G |
| Z43/2 |
Heated rear window connector sleeve |
4G |
| Z6/110 |
Interior lights ground connector sleeve |
24G |
| Z82/17 |
Rear-end door ZV connector sleeve |
29G |
