| A1 |
Instrument cluster |
30L |
| A44/9 |
Center front PTS warning element |
38L |
| A46 |
Tone signal generator |
72L |
| A49/4 |
Stationary heater radio signal receiver |
55L |
| A56 |
Tachograph |
16L |
| A9 |
Refrigerant compressor |
50A |
| A99 |
Electric step |
33A |
| A99s3 |
Anti-pinch protection switch |
33B |
| B12 |
Refrigerant pressure sensor |
46A |
| E2 |
Right lamp unit |
42A |
| E2m1 |
Headlamp range adjustment motor |
43A |
| F55/1 |
Fuse block (9 fuses) |
65L |
| F55/1f8 |
Fuse 8 (15 A), EDW, rotating beacon/tone sequence |
64K |
| F55/2 |
Fuse block (9 fuses) |
32L |
| F55/2 |
Fuse block (9 fuses) |
79A |
| F55/2f3 |
Fuse 12 (30 A), front blower |
79B |
| F55/2f6/1 |
Fuse 15 (5 A), brake system |
31K |
| F55/3 |
Fuse block (9 fuses) |
14A |
| F55/3 |
Fuse block (9 fuses) |
18A |
| F55/3 |
Fuse block (9 fuses) |
59L |
| F55/3f4 |
Fuse 4 (7. 5 A), AAG, tachograph, ADR |
14B |
| F55/3f7 |
Fuse 7 (10 A), ESM [EWM] |
18B |
| F55/3f9 |
Fuse 9 (15 A), multitone horn/roof fan |
58K |
| F55/5 |
Fuse block (9 fuses) |
62L |
| F55/5f5 |
Fuse 23 (10/15 A) electrical components, other make body/left rear socket |
62K |
| G2/2 |
Alternator |
IIA |
| G2/8 |
Alternator |
IIA |
| H4/25 |
Bass mi drange speaker |
3L |
| H4/26 |
Bass mi drange speaker |
5L |
| K23/1 |
Blower stage 1 fan relay |
79L |
| K51/10 |
Rotating beacon relay |
67L |
| K9 |
Additional fan relay |
45A |
| M13/4 |
Circulation pump |
63L |
| M13/4 |
Circulation pump |
48A |
| N10 |
SAM control unit |
33L |
| N15/5 |
EWM control unit |
20L |
| N3/20 |
CDI control unit |
26A |
| N3/21 |
CDI control unit |
26A |
| N3/28 |
CDI control unit |
27A |
| N3/30 |
CDI control unit |
21A |
| N30/4 |
ESP control unit |
32A |
| N33/3 |
Hot water auxiliary heating control unit |
53A |
| N33/3 |
Hot water auxiliary heating control unit |
53A |
| N33/3x2 |
Hot water auxiliary heater connector (4-pin) |
51E |
| N62 |
PTS control unit |
38A |
| N72/1 |
OBF control unit |
76A |
| N73 |
EIS [EZS] control unit |
36L |
| N87/6 |
Radio/radio with navigation NG |
2A |
| N97 |
Electronic level control [ENR] control unit |
40A |
| R13/1 |
Driver seat heated cushion |
78L |
| R13/2 |
Driver seat backrest heated cushion |
77L |
| R13/3 |
Front passenger seat heated cushion |
75L |
| R13/4 |
Front passenger seat backrest heated cushion |
76L |
| R14 |
Blower motor series resistor group |
81A |
| S1/1 |
Headlamp range controller |
43L |
| S157/1 |
Rotating beacon switch |
65A |
| S157/3 |
Rotating beacon with tone sequence switch |
67A |
| S157/3 |
Rotating beacon with tone sequence switch |
71A |
| S160 |
Body manufacturer electrical system switch |
61A |
| S163 |
Roof ventilator switch |
59A |
| S2/6 |
Engine start/stop switch |
22L |
| S21/2 |
Front passenger power window switch |
35A |
| S46/11 |
Heater booster/stationary heater button |
53L |
| S62/41 |
Engine hood switch |
29A |
| S77/1 |
ELC lock button |
40L |
| S77/2 |
ELC raise/lower button |
41L |
| S9/1 |
Stop lamp switch |
30A |
| S98 |
AAC [KLA] control and operating unit |
12L |
| S98 |
AAC [KLA] control and operating unit |
47L |
| S98 |
AAC [KLA] control and operating unit |
63A |
| U10 |
Valid for engine start/stop (MSS) |
22F |
| U2 |
Valid for right-hand drive vehicles |
76C |
| U72 |
Valid for all except USA, Canada |
14H |
| U72 |
Valid for all except USA, Canada |
19A |
| U72 |
Valid for all except USA, Canada |
39A |
| U72 |
Valid for all except USA, Canada |
64A |
| U72 |
Valid for all except USA, Canada |
76C |
| V22 |
Tone sequence diode |
68L |
| V22/2 |
Horn/tone sequence decoupling diode |
69L |
| W9/7 |
Left front ground point 2 |
63H |
| W9/7 |
Left front ground point 2 |
47E |
| X11 |
Diagnostic socket (16-pin) |
36A |
| X145/6 |
Body manufacturer connector |
60L |
| X18/49 |
HLS/COC connector 2 |
2G |
| X18/56 |
HLS/COC connector |
9H |
| X18/77 |
HLS/COC connector 6 |
58G |
| X18/78 |
HLS/COC connector 7 |
75G |
| X26/38 |
Engine wiring harness connector |
10E |
| X26/38 |
Engine wiring harness connector |
49E |
| X26/44 |
Engine wiring harness connector |
49F |
| X26/47 |
Engine wiring harness connector |
10F |
| X26/47 |
Engine wiring harness connector |
49F |
| X26/50 |
Engine wiring harness connector 1 |
50F |
| X26/55 |
Engine wiring harness connector 1 |
50E |
| X30/24 |
Interior CAN bus connector |
9A |
| X30/25 |
Interior CAN bus connector |
9L |
| X31/10 |
Blower stage 1 connector |
81E |
| X35/2 |
Front passenger door connector |
34E |
| X35/41 |
Driver door/MWH connector 2 |
3J |
| X35/42 |
Front passenger door connector |
5J |
| X39/67 |
Radio preinstallation connector |
5A |
| X54/29 |
Driver heated seat connector |
76H |
| X54/30 |
Front passenger heated seat connector |
74H |
| X64/13 |
Double auxiliary fan connector |
44E |
| Z151 |
Blower motor connector sleeve |
81D |
| Z28/68 |
Left cockpit speaker connector sleeve |
2E |
| Z28/69 |
Left cockpit speaker connector sleeve |
3E |
| Z28/70 |
Right cockpit speaker connector sleeve |
4E |
| Z28/71 |
Right cockpit speaker connector sleeve |
5E |
| Z3/56 |
Headlamp range adjustment tml. 15 connector sleeve |
43E |
| Z3/63 |
ADR tml. 15 connector sleeve |
14L |
| Z36/12 |
HRA [LWR] control bus connector sleeve |
42E |
| Z47/16 |
Rotating beacon with tone sequence tml. 30 connector sleeve |
66H |
| Z47/17 |
Rotating beacon with tone sequence tml. 30 connector sleeve |
66D |
| Z47/19 |
Rotating beacon with tone sequence connector sleeve |
68H |
| Z5/6 |
Roof ventilator connector sleeve |
57A |
| 11111 |
Tml. 87 connector sleeve |
22E |
| Z81/5 |
Tml. 58d connector sleeve |
35L |
