Remove/install trim strip on front door lining - AR72.12-P-1050SX

MODEL 221.0/1

Fig 1: Identifying Front Door Lining Trim Strip Remove/Install Component - Shown On Model 221.0

Courtesy of MERCEDES-BENZ USA

Shown on model 221.0

	Remove/install
1	Remove door liner (1) from rear door	Lay door lining (1) front side down on suitable subsurface to prevent damage
		Vehicles without code (Z07) Top protection	AR72.12-P-1010SX
		Vehicles with code (Z07) Top protection	AR72.12-P-1010SXS
2.1	Disconnect electrical connector from trim strip (3)	On vehicles with code (876) interior light package
3	Remove bolts (2)
4	Remove trim strip (3)
5	Install in the reverse order
