| 1 |
Low beams, request |
|
| 1 |
Low beams, request |
|
| 10 |
Synchronization, signal |
|
| 10 |
Synchronization, signal |
|
| 10 |
Synchronization, signal |
|
| 10 |
Synchronization, signal |
|
| 10 |
Synchronization, signal |
|
| 11 |
Dynamic curve illumination motor, actuation |
|
| 11 |
Dynamic curve illumination motor, actuation |
|
| 12 |
Light distribution actuator motor, actuation |
|
| 12 |
Light distribution actuator motor, actuation |
|
| 13 |
Automatic high beams, request |
21H |
| 13 |
Automatic high beams, request |
24D |
| 14 |
High beams, status |
24D |
| 14 |
High beams, status |
|
| 15 |
Automatic high beams, actuation |
23E |
| 15 |
Automatic high beams, actuation |
|
| 16 |
Automatic high beams, status |
21J |
| 2 |
Circuit 61, status |
23G |
| 2 |
Circuit 61, status |
|
| 3 |
Bi-xenon lamp with integrated ignition module, actuation |
|
| 3 |
Bi-xenon lamp with integrated ignition module, actuation |
|
| 4 |
Combination switch, status |
30A |
| 4 |
Combination switch, status |
23F |
| 4 |
Combination switch, status |
|
| 5 |
Steering angle, signal |
30C |
| 5 |
Steering angle, signal |
23F |
| 5 |
Steering angle, signal |
|
| 6 |
Wheel speed, signal |
|
| 6 |
Wheel speed, signal |
|
| 6 |
Wheel speed, signal |
|
| 7 |
Yaw rate and lateral acceleration sensor, signal |
24D |
| 7 |
Yaw rate and lateral acceleration sensor, signal |
|
| 7 |
Yaw rate and lateral acceleration sensor, signal |
|
| 7 |
Yaw rate and lateral acceleration sensor, signal |
|
| 8 |
Reverse gear, status |
23G |
| 8 |
Reverse gear, status |
28G |
| 8 |
Reverse gear, status |
|
| 9 |
Synchronization, signal |
6H |
| A1 |
Instrument cluster |
21K |
| A40/11 |
Multifunction camera |
26A |
| A80 |
Intelligent servo module for DIRECT SELECT |
30F |
| B24/15 |
Yaw rate, lateral and longitudinal acceleration sensor |
15A |
| CAN B |
Interior CAN |
17D |
| CAN B |
Interior CAN |
12D |
| CAN C |
Drive train CAN |
29G |
| CAN E |
Chassis CAN |
24G |
| CAN E |
Chassis CAN |
22D |
| CAN E |
Chassis CAN |
27D |
| CAN E |
Chassis CAN |
24F |
| CAN E |
Chassis CAN |
22B |
| CAN E |
Chassis CAN |
24E |
| CAN F |
Central CAN |
21H |
| CAN G |
Front end CAN |
19G |
| CAN G |
Front end CAN |
7L |
| CAN G |
Front end CAN |
12L |
| CAN H |
Vehicle dynamics CAN |
17B |
| Code 608 |
Adaptive Highbeam Assist |
24A |
| E1e10 |
Left bi-xenon lamp with integral ignition module |
16J |
| E1e9 |
Cornering illumination |
12J |
| E1e9 |
Cornering illumination |
14J |
| E1m2 |
Left dynamic curve illumination motor |
11J |
| E1m3 |
Left light distribution actuator motor |
13J |
| E1n1 |
Xenon headlamp control unit |
16F |
| E1n6 |
Left turn signal and cornering light voltage converter |
12H |
| E2e10 |
Right bi-xenon lamp with integral ignition module |
5J |
| E2e9 |
Cornering illumination |
4J |
| E2e9 |
Cornering illumination |
2J |
| E2m2 |
Right dynamic curve illumination motor |
1J |
| E2m3 |
Right light distribution actuator motor |
3J |
| E2n1 |
Xenon headlamp control unit |
5F |
| E2n6 |
Right turn signal and cornering light voltage converter |
2H |
| N10/1 |
Front SAM control unit with fuse and relay module |
6B |
| N3/10 |
ME-SFI [ME] control unit |
26G |
| N3/10 |
ME-SFI [ME] control unit |
26E |
| N30/6 |
Regenerative braking system control unit |
20C |
| N47-5 |
ESP control unit |
20A |
| N49 |
Steering angle sensor |
31B |
| N80 |
Steering column module |
28A |
| N93 |
Central gateway control unit |
21F |
| S4 |
Combination switch |
31B |
| U75 |
Valid for gasoline engines |
25E |
| U974 |
Not valid for full hybrid drive |
19A |
| U978 |
Valid for full hybrid drive |
19C |
