| A0 |
Color code key |
40L |
| A98 |
Panoramic sliding roof control module |
31L |
| Code 237 |
Active Blind Spot Assist |
10H |
| Code 238 |
Active Lane Keeping Assist |
10H |
| F32/4 |
Interior prefuse box |
3L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
12A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
36A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
20A |
| N10/2f141 |
Fuse 141 |
15C |
| N10/2f142 |
Fuse 142 |
7C |
| N10/2f143 |
Fuse 143 |
19C |
| N10/2f144 |
Fuse 144 |
20C |
| N10/2f145 |
Fuse 145 |
23C |
| N10/2f146 |
Fuse 146 |
24C |
| N10/2f148 |
Fuse 148 |
31C |
| N10/2f148 |
Fuse 148 |
27C |
| N10/2kM |
Circuit 15 (2)/spare 1 relay (changeover contact) |
3A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
27L |
| N25/6 |
Rear seats control unit |
20L |
| N28/1 |
Trailer recognition control unit |
23L |
| N62 |
PTS control unit |
7L |
| N62 |
PTS control unit |
8L |
| N62 |
PTS control unit |
8L |
| N62/1 |
Radar sensors control unit (SGR) |
12L |
| N62/1 |
Radar sensors control unit (SGR) |
11L |
| N62/2 |
Video and radar sensor system control unit |
12L |
| N66/10 |
Backup camera voltage supply module |
16L |
| N66/2 |
Backup camera control unit |
16L |
| N82/1 |
Vehicle power supply control unit |
3L |
| U52 |
Valid for {{Japan}} |
15F |
| U533 |
Valid for trailer hitch |
22F |
| U538 |
Valid for Parktronic System |
6F |
| U538 |
Valid for Parktronic System |
6G |
| U538 |
Valid for Parktronic System |
6G |
| U54 |
Valid for all except {{Japan}} |
15G |
| U899 |
Valid for backup camera |
14F |
| U899 |
Valid for backup camera |
14G |
| U909 |
Valid for DISTRONIC PLUS |
10F |
| U909 |
Valid for DISTRONIC PLUS |
11G |
| U909 |
Valid for DISTRONIC PLUS |
10H |
| U987 |
Valid for Distronic Plus (light) |
10G |
| X25/8 |
Overhead control panel and FFS [RBA] connector |
31G |
| Z7/40 |
Tml. 30 connector sleeve |
27G |
| Z7/80 |
Panoramic sliding sunroof circuit 30 connector sleeve |
31H |
