| F32 |
Front prefuse |
2L |
| F32/3 |
Engine compartment prefuse box |
4L |
| F32/3f5 |
Fuse 5 |
4K |
| F32f6 |
Fuse 6 |
2K |
| M4/7 |
Engine and AC electric suction fan with integrated control |
4A |
| M4/7 |
Engine and AC electric suction fan with integrated control |
12A |
| M4/7 |
Engine and AC electric suction fan with integrated control |
20A |
| M4/7 |
Engine and AC electric suction fan with integrated control |
26A |
| N10/1 |
Front SAM control unit with fuse and relay module |
6L |
| N10/1 |
Front SAM control unit with fuse and relay module |
11L |
| N3/10 |
ME-SFI [ME] control unit |
16L |
| N3/10 |
ME-SFI [ME] control unit |
24L |
| N3/10 |
ME-SFI [ME] control unit |
33L |
| N3/10 |
ME-SFI [ME] control unit |
29L |
| N3/9 |
CDI control unit |
20L |
| R15 |
Electric suction fan series resistor |
26L |
| R15 |
Electric suction fan series resistor |
35L |
| U1028 |
Valid for engine 157 |
22F |
| U1028 |
Valid for engine 157 |
13F |
| U1028 |
Valid for engine 157 |
9F |
| U152 |
Valid for engine 156 |
22E |
| U152 |
Valid for engine 156 |
9E |
| U484 |
Valid for M273 ME |
15E |
| U484 |
Valid for M273 ME |
5E |
| U484 |
Valid for M273 ME |
13F |
| U779 |
Valid for engine 275 |
13F |
| U779 |
Valid for engine 275 |
9F |
| U932 |
Valid for engine 642 BLUETEC |
5F |
| U932 |
Valid for engine 642 BLUETEC |
13F |
| U932 |
Valid for engine 642 BLUETEC |
18E |
| U966 |
Valid for engine 275.953 |
27E |
| U967 |
Valid for engine 275.982 |
31E |
| U968 |
Valid for mild hybrid drive |
15F |
| U968 |
Valid for mild hybrid drive |
13E |
| W2 |
Ground (right front, at lamp unit) |
14L |
| W9 |
Ground (left front, at lamp unit) |
14L |
| Z7/5 |
Circuit 87 connector sleeve |
10G |
| Z7/5 |
Circuit 87 connector sleeve |
6G |
| Z7/75 |
Circuit 87 D3 connector sleeve |
6H |
