| E1 |
Left front lamp unit |
6K |
| E1 |
Left front lamp unit |
39K |
| E2 |
Right front lamp unit |
8K |
| E2 |
Right front lamp unit |
41K |
| E2/3 |
Right daytime running lamps headlamp |
35L |
| E2/3 |
Right daytime running lamps headlamp |
37L |
| E2b1 |
Right active curve illumination position sensor |
26H |
| E2b1 |
Right active curve illumination position sensor |
65H |
| E2b2 |
Right light distribution position sensor |
70H |
| E2e1 |
Right high beam |
74H |
| E2e10 |
Right bi-xenon lamp with integral ignition module |
30H |
| E2e10 |
Right bi-xenon lamp with integral ignition module |
68H |
| E2e11 |
Right infrared lamp |
20H |
| E2e11 |
Right infrared lamp |
58H |
| E2e2 |
Right low beam |
18H |
| E2e3 |
Right standing and parking lamp |
16H |
| E2e3 |
Right standing and parking lamp |
51H |
| E2e3 |
Right standing and parking lamp |
53H |
| E2e5 |
Right turn signal lamp |
19H |
| E2e5 |
Right turn signal lamp |
54H |
| E2e5 |
Right turn signal lamp |
56H |
| E2e9 |
Cornering illumination |
21H |
| E2e9 |
Cornering illumination |
60H |
| E2l1 |
Right high beam solenoid |
25H |
| E2l1 |
Right high beam solenoid |
63H |
| E2m1 |
Right headlamp range adjustment motor |
28H |
| E2m1 |
Right headlamp range adjustment motor |
67H |
| E2m2 |
Right dynamic curve illumination motor |
23H |
| E2m2 |
Right dynamic curve illumination motor |
61H |
| E2m3 |
Right light distribution actuator motor |
72H |
| E2n1 |
Xenon headlamp control unit |
9L |
| E2n1 |
Xenon headlamp control unit |
17L |
| E2n1 |
Xenon headlamp control unit |
24L |
| E2n1 |
Xenon headlamp control unit |
30L |
| E2n1 |
Xenon headlamp control unit |
42L |
| E2n1 |
Xenon headlamp control unit |
51L |
| E2n1 |
Xenon headlamp control unit |
68L |
| E2n1 |
Xenon headlamp control unit |
62L |
| E2n1 |
Xenon headlamp control unit |
74L |
| E2n5 |
Right standing and parking light voltage converter |
53H |
| E2n6 |
Right turn signal and cornering light voltage converter |
59H |
| E2n6 |
Right turn signal and cornering light voltage converter |
56H |
| E5/2 |
Right fog lamp |
4L |
| E5/2 |
Right fog lamp |
34L |
| F32 |
Front prefuse |
2L |
| F32/3 |
Engine compartment prefuse box |
2L |
| F32/3 |
Engine compartment prefuse box |
32L |
| F32/3f6 |
Fuse 6 |
2K |
| F32/3f6 |
Fuse 6 |
32K |
| F32f6 |
Fuse 6 |
2K |
| N10/1 |
Front SAM control unit with fuse and relay module |
5A |
| N10/1 |
Front SAM control unit with fuse and relay module |
12A |
| N10/1 |
Front SAM control unit with fuse and relay module |
34A |
| N10/1 |
Front SAM control unit with fuse and relay module |
42A |
| N10/1 |
Front SAM control unit with fuse and relay module |
49A |
| N10/1f27 |
Fuse 27 |
12C |
| N10/1f27 |
Fuse 27 |
45C |
| N10/1kD |
Circuit 15 (2)/spare 1 relay (changeover contact) |
4A |
| N10/1kD |
Circuit 15 (2)/spare 1 relay (changeover contact) |
33A |
| U1022 |
Valid for Intelligent Light System |
59H |
| U1022 |
Valid for Intelligent Light System |
64G |
| U1022 |
Valid for Intelligent Light System |
70G |
| U1022 |
Valid for Intelligent Light System |
52G |
| U1022 |
Valid for Intelligent Light System |
55G |
| U1022 |
Valid for Intelligent Light System |
36H |
| U220 |
Valid without Night View Assist |
74G |
| U735 |
Valid for bi-xenon |
57G |
| U735 |
Valid for bi-xenon |
50G |
| U735 |
Valid for bi-xenon |
63G |
| U735 |
Valid for bi-xenon |
54G |
| U735 |
Valid for bi-xenon |
33H |
| U907 |
Valid for night view assist |
19G |
| U915 |
Valid for cornering illumination |
21G |
| U915 |
Valid for cornering illumination |
59G |
| U971 |
Valid for daytime running lamps |
35H |
| W3/1 |
Ground (right front wheelhouse) |
11F |
| W3/1 |
Ground (right front wheelhouse) |
4H |
| W3/1 |
Ground (right front wheelhouse) |
43F |
| W3/1 |
Ground (right front wheelhouse) |
34G |
| X219 |
Daytime running lights/front fog lamps and engine wiring harness connector |
33G |
