| 1 |
Instrument cluster, message |
27K |
| 1 |
Instrument cluster, message |
25F |
| 1 |
Instrument cluster, message |
28F |
| 1 |
Instrument cluster, message |
7B |
| 1 |
Instrument cluster, message |
7E |
| 1 |
Instrument cluster, message |
17E |
| 1 |
Instrument cluster, message |
25E |
| 1 |
Instrument cluster, message |
26E |
| 1 |
Instrument cluster, message |
27E |
| 1 |
Instrument cluster, message |
26J |
| 2 |
Circuit 15, status |
25H |
| 2 |
Circuit 15, status |
26J |
| A1 |
Instrument cluster |
25K |
| A13 |
Electric parking brake control unit |
27B |
| A40/11 |
Multifunction camera |
12C |
| A40/3 |
COMAND control unit |
30J |
| A6n1 |
STH or HB control unit |
41C |
| A76 |
Left front reversible emergency tensioning retractor |
23D |
| A76/1 |
Right front reversible emergency tensioning retractor |
23E |
| A8/1 |
Transmitter key |
23J |
| A89 |
DTR control unit |
5D |
| A89 |
DTR control unit |
5B |
| CAN B |
Interior CAN |
32G |
| CAN B |
Interior CAN |
42G |
| CAN D |
Diagnostic CAN |
25E |
| CAN E |
Chassis CAN |
4G |
| CAN E |
Chassis CAN |
12G |
| CAN E |
Chassis CAN |
20G |
| CAN E |
Chassis CAN |
22H |
| CAN F |
Central CAN |
28K |
| CAN F |
Central CAN |
25H |
| CAN G |
Front end CAN |
27E |
| CAN G |
Front end CAN |
29E |
| CAN H |
Vehicle dynamics CAN |
18D |
| CAN H |
Vehicle dynamics CAN |
6E |
| CAN H |
Vehicle dynamics CAN |
6C |
| Code 219 |
DISTRONIC |
4A |
| Code 220 |
PARKTRONIC (PTS) |
18H |
| Code 220 |
PARKTRONIC (PTS) |
42C |
| Code 228 |
Stationary heater |
39B |
| Code 230 |
Exclusive parking assist |
18J |
| Code 233 |
DISTRONIC PLUS |
4D |
| Code 233 |
DISTRONIC PLUS |
4B |
| Code 238 |
Active Lane Keeping Assist |
11B |
| Code 238 |
Active Lane Keeping Assist |
4E |
| Code 275 |
Memory function (driver seat, steering column, outside mirror) |
38H |
| Code 359 |
TELEAID emergency call system |
24A |
| Code 475 |
Tire pressure monitor |
13B |
| Code 475 |
Tire pressure monitor |
41H |
| Code 476 |
Automatic lane detection |
11B |
| Code 487 |
Active Body Control (ABC) |
15H |
| Code 494 |
USA version |
44H |
| Code 513 |
Speed Limit Assist |
11B |
| Code 550 |
Trailer hitch |
36B |
| Code 608 |
Adaptive Highbeam Assist |
11C |
| Code 610 |
Night View Assist |
17A |
| Code 610 |
Night View Assist |
20A |
| Code 889 |
KEYLESS-GO |
33B |
| E1n1 |
Xenon headlamp control unit |
29B |
| E2n1 |
Xenon headlamp control unit |
29C |
| N10/1 |
Front SAM control unit with fuse and relay module |
47E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
32C |
| N101 |
Night vision assist control unit |
17B |
| N101 |
Night vision assist control unit |
21B |
| N110 |
Weight Sensing System (WSS) control unit |
45J |
| N123/4 |
Emergency call system control unit |
25B |
| N2/7 |
Restraint systems control unit |
2H |
| N28/1 |
Trailer recognition control unit |
37C |
| N3/10 |
ME-SFI [ME] control unit |
7H |
| N3/10 |
ME-SFI [ME] control unit |
10J |
| N3/10 |
ME-SFI [ME] control unit |
12J |
| N3/9 |
CDI control unit |
5H |
| N32/1 |
Left front seat control unit |
39J |
| N32/2 |
Right front seat control unit |
39J |
| N47-5 |
ESP control unit |
16D |
| N51 |
AIRMATIC with ADS control unit |
2C |
| N51/2 |
ABC control unit |
16J |
| N62 |
PTS control unit |
20J |
| N62 |
PTS control unit |
42C |
| N62/1 |
Radar sensors control unit (SGR) |
9B |
| N62/2 |
Video and radar sensor system control unit |
9E |
| N69/1 |
Left front door control unit |
33H |
| N69/2 |
Right front door control unit |
33H |
| N69/3 |
Rear left door control unit |
36H |
| N69/4 |
Right rear door control unit |
36H |
| N69/5 |
KEYLESS-GO control unit |
34C |
| N73 |
EIS [EZS] control unit |
23H |
| N80 |
Steering column module |
20D |
| N88 |
TPM [RDK] control unit |
42J |
| N88 |
TPM [RDK] control unit |
14C |
| N93 |
Central gateway control unit |
26F |
| U1018 |
Valid for gasoline engine 276 |
9H |
| U1019 |
Valid for engine 278 |
12H |
| U152 |
Valid for engine 156 |
11H |
| U484 |
Valid for M273 ME |
7H |
| U52 |
Valid for {{Japan}} |
29J |
| U54 |
Valid for all except {{Japan}} |
29J |
| U736 |
Not valid for ABC |
1B |
| U779 |
Valid for engine 275 |
9H |
| U819 |
Valid for engine 272 |
6H |
| U880 |
Valid for engine 642 |
4H |
| U882 |
Valid for engine 629 |
4H |
| U932 |
Valid for engine 642 BLUETEC |
4H |
