| 1 |
Telematics CAN active, signal |
21F |
| 1 |
Telematics CAN active, signal |
24F |
| 1 |
Telematics CAN active, signal |
|
| 2 |
Analog picture signal, signal |
20E |
| 2 |
Analog picture signal, signal |
26E |
| 3 |
Analog audio signal, signal |
19H |
| 3 |
Analog audio signal, signal |
25H |
| 3 |
Analog audio signal, signal |
20E |
| 3 |
Analog audio signal, signal |
26E |
| 3 |
Analog audio signal, signal |
22C |
| 3 |
Analog audio signal, signal |
|
| 4 |
Infrared, signal |
21H |
| 4 |
Infrared, signal |
27H |
| 4 |
Infrared, signal |
18F |
| 4 |
Infrared, signal |
27F |
| 5 |
Audio, signal |
9J |
| 5 |
Audio, signal |
11H |
| 6 |
Speaker, actuation |
6H |
| 6 |
Speaker, actuation |
7K |
| 6 |
Speaker, actuation |
12J |
| A2 |
Radio |
6D |
| A2/56 |
Radio with auto pilot system |
8D |
| A40/3 |
COMAND control unit |
11D |
| A40/4 |
DVD player |
22C |
| A40/5 |
Left rear display |
20E |
| A40/6 |
Right rear display |
25E |
| CAN A |
Telematics CAN |
|
| CAN A |
Telematics CAN |
|
| CAN A |
Telematics CAN |
|
| Code 510 |
Audio 20 with CD changer |
|
| Code 511 |
Audio 50 APS incl. DVD changer |
|
| Code 512 |
COMAND APS with DVD changer |
|
| Code 512 |
COMAND APS with DVD changer |
|
| Code 523 |
Audio 20 radio |
|
| Code 525 |
Audio 50 APS radio (CD) |
|
| Code 527 |
COMAND APS |
|
| Code 527 |
COMAND APS |
|
| Code 528 |
COMAND with DVD changer |
|
| Code 528 |
COMAND with DVD changer |
|
| Code 810 |
Sound system |
|
| H4/1h1 |
Left front door tweeter |
6J |
| H4/1h1 |
Left front door tweeter |
14H |
| H4/1h2 |
Left front door bass speaker |
6J |
| H4/1h2 |
Left front door bass speaker |
14J |
| H4/27 |
Center instrument panel speaker |
14K |
| H4/2h1 |
Right front door tweeter |
6J |
| H4/2h1 |
Right front door tweeter |
14J |
| H4/2h2 |
Right front door bass speaker |
6J |
| H4/2h2 |
Right front door bass speaker |
14J |
| H4/3 |
Left rear door speaker |
14J |
| H4/3 |
Left rear door speaker |
6K |
| H4/38 |
Rear bass speaker |
7L |
| H4/4 |
Right rear door speaker |
14K |
| H4/4 |
Right rear door speaker |
6K |
| H4/54 |
Left rear surround speaker |
14K |
| H4/57 |
Right rear surround speaker |
14K |
| MOST |
Media Oriented System Transport |
|
| N40/3 |
Sound system amplifier control unit |
10H |
| N40/9 |
Rear bass speaker amplifier |
8J |
| U500 |
Not valid for sound system |
5H |
