| A0 |
Color code key |
32L |
| A2 |
Radio |
13L |
| A2/19 |
Antennenverstarker FM 2, DAB und TV 1 |
22L |
| A2/19 |
Antennenverstarker FM 2, DAB und TV 1 |
24L |
| A2/30 |
Navigation module |
4A |
| A2/30 |
Navigation module |
12A |
| A2/30 |
Navigation module |
20A |
| A2/30-1 |
Cradle for navigation module |
1C |
| A2/98 |
FM/TMC antenna splitter |
19L |
| A28/11 |
Multifunction antenna |
26L |
| CAN A |
Telematics CAN |
7K |
| N10/1 |
Front SAM control unit with fuse and relay module |
4L |
| N10/1f11 |
Fuse 11 |
3L |
| U57 |
Valid for model 218.9 |
23E |
| U58 |
Valid for model 218.3 |
21E |
| W19 |
Right front seat crossmember ground point |
4G |
| X18/35 |
Instrument panel and vehicle floor electrical connector |
2F |
| X18/35 |
Instrument panel and vehicle floor electrical connector |
26G |
| X30/35 |
Telematics CAN voltage distributor electrical connector |
7L |
| X8/46 |
Right vehicle interior and trunk lid/liftgate electrical connector |
24G |
| Z37/6z3 |
Telematics CAN (high) connector sleeve |
6G |
| Z37/7z3 |
Telematics CAN (low) connector sleeve |
7G |
