| A45 |
Fanfare horns and airbag clock spring contact |
14D |
| A45 |
Fanfare horns and airbag clock spring contact |
24D |
| A45 |
Fanfare horns and airbag clock spring contact |
45D |
| A74 |
Steering wheel heater electronics |
24L |
| CAN E |
Chassis CAN |
8K |
| M99 |
Steering wheel vibration motor |
50L |
| N10/1 |
Front SAM control unit with fuse and relay module |
2L |
| N10/1 |
Front SAM control unit with fuse and relay module |
19L |
| N10/1 |
Front SAM control unit with fuse and relay module |
40L |
| N135 |
Steering wheel electronics |
49E |
| N135 |
Steering wheel electronics |
55E |
| N135 |
Steering wheel electronics |
35F |
| N135 |
Steering wheel electronics |
31F |
| N135 |
Steering wheel electronics |
26F |
| N135 |
Steering wheel electronics |
59E |
| N2/7 |
Restraint systems control unit |
11L |
| N49 |
Steering angle sensor |
66D |
| N80 |
Steering column module |
4A |
| N80 |
Steering column module |
72A |
| N80 |
Steering column module |
11A |
| N80 |
Steering column module |
20A |
| N80 |
Steering column module |
28A |
| N80 |
Steering column module |
35A |
| N80 |
Steering column module |
45A |
| N80 |
Steering column module |
53A |
| N80 |
Steering column module |
61A |
| N80 |
Steering column module |
68A |
| R12/13 |
Driver airbag ignition squib 1 |
16K |
| R12/13 |
Driver airbag ignition squib 1 |
16K |
| R12/14 |
Driver airbag ignition squib 2 |
15K |
| R12/14 |
Driver airbag ignition squib 2 |
15K |
| R22/4 |
Steering wheel heater |
22L |
| R22/4 |
Steering wheel heater |
42L |
| R22/4 |
Steering wheel heater |
48L |
| R22/4b1 |
Heater coil temperature sensor |
48L |
| R22/4b1 |
Heater coil temperature sensor |
23L |
| R22/4r1 |
Heater coil |
43L |
| R22/4r1 |
Heater coil |
22L |
| S110 |
Left multifunction steering wheel button group |
30L |
| S110 |
Left multifunction steering wheel button group |
26L |
| S110 |
Left multifunction steering wheel button group |
55L |
| S110/1 |
Steering wheel gear shifter MINUS |
53L |
| S110/2 |
Left steering wheel gear shifter |
34L |
| S110s1 |
Scroll forward/back button |
29L |
| S110s1 |
Scroll forward/back button |
55L |
| S110s1 |
Scroll forward/back button |
55J |
| S110s1 |
Scroll forward/back button |
58L |
| S110s1 |
Scroll forward/back button |
58J |
| S110s3 |
System selection button |
54K |
| S110s3 |
System selection button |
56K |
| S110s3 |
System selection button |
57K |
| S110s3 |
System selection button |
59K |
| S110s3 |
System selection button |
31L |
| S110s4 |
"Back" and SBS off button |
30L |
| S110s4 |
"Back" and SBS off button |
31L |
| S110s4 |
"Back" and SBS off button |
56L |
| S110s5 |
Fanfare horn system button |
27L |
| S110s5 |
Fanfare horn system button |
56J |
| S110s5 |
Fanfare horn system button |
59J |
| S110s6 |
OK button |
55K |
| S110s6 |
OK button |
58K |
| S111 |
Right multifunction steering wheel button group |
32L |
| S111 |
Right multifunction steering wheel button group |
28L |
| S111 |
Right multifunction steering wheel button group |
58L |
| S111/1 |
Steering wheel gear shifter PLUS |
52L |
| S111/2 |
Right steering wheel gear shifter |
35L |
| S111s1 |
Buttons + and - for setting specific functions and volume control |
31L |
| S111s3 |
Accept/terminate phone call button |
33L |
| S111s4 |
VCS [SBS] on button |
32L |
| S111s5 |
Fanfare horn system button |
28L |
| S16/13 |
Gear selector switch DIRECT SELECT |
72D |
| S4 |
Combination switch |
61D |
| S40/4 |
CC [TPM] switch |
69D |
| S40/4r1 |
DTR distance potentiometer |
70D |
| S40/4s1 |
Resume from memory |
69D |
| S40/4s2 |
Decelerate and set |
68D |
| S40/4s3 |
Accelerate and set |
68D |
| S40/4s4 |
Off |
70D |
| S40/4s5 |
Control contact |
70D |
| S4s1 |
Left and right turn signal switch |
60D |
| S4s2 |
Headlamp flasher/high beam switch |
60D |
| S4s3 |
Low beam switch |
61D |
| S4s4 |
Windshield washer system switch |
61D |
| S4s5 |
Wipe switch |
62D |
| S59 |
Steering column adjustment switch |
63D |
| S59/1 |
Steering column adjustment/steering wheel heater switch |
63D |
| S59/1e1 |
Steering wheel heater function indicator lamp |
64D |
| S59/1s1 |
Steering column adjustment raise/lower, forward/back switch |
63D |
| S59/1s2 |
Steering wheel heater switch |
64D |
| S97/1 |
Steering column adjustment lock indicator switch |
5L |
| U34 |
Valid for automatic lane recognition |
49G |
| U504 |
Valid for DTR |
70A |
| U73 |
Valid for ESC [ELV] |
62A |
| U744 |
Valid for steering wheel heater |
62A |
| U744 |
Valid for steering wheel heater |
17F |
| U744 |
Valid for steering wheel heater |
36D |
| U873 |
Valid for steering wheel gear shift |
26E |
| U873 |
Valid for steering wheel gear shift |
51G |
| W34 |
Ground (left footwell) |
3E |
| W34 |
Ground (left footwell) |
17L |
| W34 |
Ground (left footwell) |
37L |
| X30/31 |
Chassis CAN/cockpit voltage distributor connector |
8L |
