| A80 |
Intelligent servo module for DIRECT SELECT |
30L |
| N118 |
Fuel pump control unit |
11L |
| N118 |
Fuel pump control unit |
15L |
| N118 |
Fuel pump control unit |
7L |
| N15/3 |
ETC [EGS] control unit |
38L |
| N3/10 |
ME-SFI [ME] control unit |
19L |
| N3/10 |
ME-SFI [ME] control unit |
22L |
| N3/10 |
ME-SFI [ME] control unit |
26L |
| N89 |
Transmission oil auxiliary pump control unit |
3L |
| U1019 |
Valid for engine 278 |
5G |
| U1019 |
Valid for engine 278 |
24G |
| U1028 |
Valid for engine 157 |
5G |
| U1028 |
Valid for engine 157 |
24G |
| U152 |
Valid for engine 156 |
21G |
| U152 |
Valid for engine 156 |
9G |
| U252 |
Valid for ECO start/stop function |
1G |
| U484 |
Valid for M273 ME |
21G |
| U484 |
Valid for M273 ME |
32G |
| U779 |
Valid for engine 275 |
36G |
| U897 |
Valid for intelligent servo module for DIRECT SELECT |
28G |
| U966 |
Valid for engine 275.953 |
13G |
| U967 |
Valid for engine 275.982 |
9G |
| W18 |
Ground (left front seat crossmember) |
21E |
| X30/21 |
Drive train CAN voltage distributor connector |
21A |
| X30/21 |
Drive train CAN voltage distributor connector |
5A |
| X30/21 |
Drive train CAN voltage distributor connector |
12A |
| X30/21 |
Drive train CAN voltage distributor connector |
28A |
| X30/21 |
Drive train CAN voltage distributor connector |
35A |
| Y3/8 |
Electric control unit (VGS) |
34L |
