Exterior lights, location of components - GF82.10-P-0003-02SX

MODEL 216.3, 221.0 /1 up to Model Year 8

Shown on model 221.0 without code (487)

Active Body Control (ABC)

Fig 1: Exterior Lights Component Locations - Shown On Model 221.0 Without Code (487)

Courtesy of MERCEDES-BENZ USA
