Block diagram of exterior lights - GF82.10-P-0003-03SXA

MODEL 216.3 up to Model Year 8

MODEL 221.0 /1 up to Model Year 8 with CODE (615) Bi-xenon headlamp unit with integrated curve illumination

Fig 1: Exterior Lights Block Diagram

Courtesy of MERCEDES-BENZ USA
