| A85/1 |
Right door lock unit |
44K |
| CAN B |
Interior CAN |
4K |
| E17/12 |
Right door inside handle illumination |
23L |
| E17/12 |
Right door inside handle illumination |
28L |
| E17/4 |
Right door entrance/exit lamp |
19L |
| E17/4 |
Right door entrance/exit lamp |
25L |
| E17/44e1 |
Right door trim strip illumination, lamp 1 |
20L |
| E17/44e1 |
Right door trim strip illumination, lamp 1 |
27L |
| E17/44e1x1 |
Right door trim strip illumination connector, lamp 1 |
20L |
| E17/44e2 |
Right door trim strip illumination, lamp 2 |
22L |
| E17/44e2 |
Right door trim strip illumination, lamp 2 |
30L |
| E17/44e2x1 |
Right door trim strip illumination connector, lamp 2 |
21L |
| F1/6 |
Right instrument panel fuse box |
2L |
| F1/6f70 |
Fuse 70 |
1K |
| M10/4 |
Right front power window motor |
7L |
| M21/2 |
Right electrically adjustable and heated outside mirror |
14K |
| N69/2 |
Right door control unit |
4A |
| N69/2 |
Right door control unit |
12A |
| N69/2 |
Right door control unit |
20A |
| N69/2 |
Right door control unit |
28A |
| N69/2 |
Right door control unit |
37A |
| N69/2 |
Right door control unit |
45A |
| S21/2 |
Front passenger power window switch |
34L |
| S23 |
Right front seat operation switch group |
37L |
| S23s1 |
Head restraint adjustment switch |
36K |
| S23s11 |
Seat ventilation switch |
38K |
| S23s12 |
Heated seat switch |
38K |
| S23s2 |
Seat cushion fore/aft switch |
37K |
| S23s3 |
Fore/aft, height and inclination adjustment switch |
37K |
| S23s5 |
Backrest switch |
36K |
| S23s6 |
Memory switch |
38J |
| S23s7 |
Memory 1 switch |
38J |
| S23s8 |
Memory 2 switch |
38J |
| S23s9 |
Memory 3 switch |
38J |
| S85/6 |
Right interior CL [ZV] switch |
41L |
| U177 |
Not valid for ambiance illumination |
22F |
| U177 |
Not valid for ambiance illumination |
28F |
| U884 |
Valid for ambiance illumination |
20F |
| U884 |
Valid for ambiance illumination |
26F |
| U884 |
Valid for ambiance illumination |
29F |
| W15/1 |
Ground (right footwell) |
2L |
| X157/6 |
Right door trim strip illumination separating point |
26G |
| X157/6 |
Right door trim strip illumination separating point |
30G |
| X30/33 |
Right interior CAN/FFS [RBA] voltage distributor connector |
4L |
