| 1 |
Comfort closing, request |
5H |
| 1 |
Comfort closing, request |
10H |
| 1 |
Comfort closing, request |
13H |
| 1 |
Comfort closing, request |
18H |
| 1 |
Comfort closing, request |
13D |
| 1 |
Comfort closing, request |
19E |
| 1 |
Comfort closing, request |
18D |
| 2 |
Access authorization code, signal |
4D |
| 3 |
Enable comfort closing, signal |
11D |
| 4 |
Power window motor, actuation |
14J |
| 4 |
Power window motor, actuation |
19J |
| 4 |
Power window motor, actuation |
19B |
| 4 |
Power window motor, actuation |
22E |
| 5 |
Tilting/sliding roof motor, actuation |
3K |
| 6 |
Panoramic sliding roof roller sun blind drive unit, actuation |
8K |
| 6 |
Panoramic sliding roof roller sun blind drive unit, actuation |
8J |
| A17/1 |
Left front KEYLESS GO door handle |
15B |
| A17/2 |
Right front KEYLESS GO door handle |
15B |
| A17/3 |
Left rear KEYLESS GO door handle |
15B |
| A17/4 |
Right rear KEYLESS GO door handle |
15B |
| A98 |
Panoramic sliding roof control module |
10J |
| A98m1 |
Panoramic sliding roof motor |
7J |
| A98n1 |
Panoramic sliding roof control unit |
10J |
| CAN B |
Interior CAN |
12H |
| CAN B |
Interior CAN |
10H |
| CAN B |
Interior CAN |
6E |
| CAN B |
Interior CAN |
6E |
| CAN B |
Interior CAN |
17H |
| CAN B |
Interior CAN |
17D |
| CAN B |
Interior CAN |
17E |
| Code 413 |
Panoramic sliding sunroof |
6J |
| Code 414 |
Electric glass tilting/sliding roof |
1J |
| M10/3 |
Left front door power window motor |
15K |
| M10/4 |
Right front door power window motor |
23E |
| M10/5 |
Left rear door power window motor |
21J |
| M10/6 |
Right rear door power window motor |
21B |
| M12 |
Tilting/sliding roof drive unit |
2J |
| M12/5 |
Panoramic sliding roof roller sun blind drive unit |
7K |
| M12/5m1 |
Panoramic sliding roof roller sun blind motor |
7K |
| M12m1 |
Tilting/sliding roof motor |
2J |
| N69/1 |
Left front door control unit |
12J |
| N69/2 |
Right front door control unit |
20D |
| N69/3 |
Left rear door control unit |
17J |
| N69/4 |
Right rear door control unit |
17A |
| N69/5 |
KEYLESS-GO control unit |
12E |
| N70 |
Overhead control panel control unit |
5J |
| N73 |
Electronic ignition switch control unit |
3D |
| U57 |
Valid for model 204.2 |
16A |
| U57 |
Valid for model 204.2 |
14A |
| U57 |
Valid for model 204.2 |
16J |
| U58 |
Valid for model 204.0 |
16A |
| U58 |
Valid for model 204.0 |
14A |
| U58 |
Valid for model 204.0 |
16J |
| U59 |
Valid for model 204.9 |
16B |
| U59 |
Valid for model 204.9 |
14B |
| U59 |
Valid for model 204.9 |
16J |
