| A85/3 |
Left rear door lock |
17 L |
| A85/4 |
Right rear door lock |
19 L |
| CAN B |
Interior CAN |
8 K |
| F32 |
Front electrical prefuse box |
3 L |
| F32 |
Front electrical prefuse box |
30 L |
| F32f106 |
Prefuse 106 |
1 K |
| F32f90 |
Prefuse 90 |
2 K |
| N10/1 |
Front SAM control module with fuse and relay module |
22 L |
| N10/2 |
Rear SAM control module with fuse and relay module |
4 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
12 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
20 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
28 A |
| N30/4 |
Electronic Stability Program control unit |
26 L |
| S54/5 |
Left rear backrest inclination switch |
11 L |
| S54/6 |
Right rear backrest inclination switch |
12 L |
| S54/7 |
Left rear backrest lock switch |
13 L |
| S54/8 |
Right rear backrest lock switch |
14 L |
| U804 |
Valid for rear backrest adjustment |
10 F |
| W18 |
Left front seat crossmember ground point |
11 G |
| W18 |
Left front seat crossmember ground point |
18 L |
| W19 |
Right front seat crossmember ground point |
12 G |
| W19 |
Right front seat crossmember ground point |
20 L |
| W7 |
Right wheelhouse trunk ground point |
4 G |
| W7/1 |
Right taillamp trunk ground point |
14 G |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
8 L |
| X35/3 |
Left rear door electrical connector |
16 H |
| X35/4 |
Right rear door electrical connector |
18 H |
