| E18/4 |
Right trunk lamp |
13 L |
| E3 |
Left rear lamp unit |
19 L |
| E3e1 |
Left rear turn signal lamp |
18 L |
| E3e10 |
Left inner stop lamp and taillamp |
16 L |
| E3e3 |
Left backup lamp |
20 L |
| E3e5 |
Left rear fog lamp |
19 L |
| E3e9 |
Left stop lamp and taillamp and parking lamp |
17 L |
| E4 |
Right rear lamp unit |
23 L |
| E4e1 |
Right rear turn signal lamp |
22 L |
| E4e10 |
Right inner stop lamp and taillamp |
26 L |
| E4e3 |
Right backup lamp |
23 L |
| E4e5 |
Right rear fog lamp |
23 L |
| E4e9 |
Right stop lamp and taillamp and parking lamp |
25 L |
| E6/3 |
Left rear side-marker lamp |
18 L |
| E6/4 |
Right rear side-marker lamp |
21 L |
| F32 |
Front electrical prefuse box |
3 L |
| F32f106 |
Prefuse 106 |
1 K |
| F32f90 |
Prefuse 90 |
2 K |
| M14/10 |
Tank cap central locking motor |
11 L |
| N10/2 |
Rear SAM control module with fuse and relay module |
4 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
12 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
20 A |
| N10/2 |
Rear SAM control module with fuse and relay module |
26 A |
| S88/10 |
Trunk lid emergency opening switch |
10 L |
| W7 |
Right wheelhouse trunk ground point |
5 G |
| W7 |
Right wheelhouse trunk ground point |
9 G |
| W7 |
Right wheelhouse trunk ground point |
13 G |
| W7 |
Right wheelhouse trunk ground point |
15 G |
| W7 |
Right wheelhouse trunk ground point |
21 G |
| W7/1 |
Right taillamp trunk ground point |
4 G |
