| A9 |
Refrigerant compressor |
9 L |
| M4/7 |
Combustion engine and air conditioning with integrated control fan motor |
3 L |
| N10/1 |
Front SAM control module with fuse and relay module |
4 A |
| N10/1 |
Front SAM control module with fuse and relay module |
12 A |
| N10/1 |
Front SAM control module with fuse and relay module |
20 A |
| N10/1 |
Front SAM control module with fuse and relay module |
28 A |
| N10/1f15 |
Fuse 15 |
23 A |
| N10/1f16 |
Fuse 16 |
19 A |
| N10/1f22 |
Fuse 22 |
3 A |
| N10/1f33 |
Fuse 33 |
15 A |
| N10/1f34 |
Fuse 34 |
21 A |
| N10/1f8 |
Fuse 8 |
25 A |
| N10/1kN |
Engine circuit 87 relay |
1 A |
| N10/1kR |
Chassis circuit 87 relay |
14 A |
| N15/5 |
Electronic selector lever module control module |
19 L |
| N2/10 |
Supplemental restraint system control unit |
24 L |
| N3/10 |
ME-SFI [ME] control module |
12 L |
| S16/2 |
Backup lamp switch |
21 L |
| U24 |
Valid for manual transmission |
21 F |
| W15/7 |
Right front footwell ground point |
22 H |
| X26 |
Interior and engine wiring harness electrical connector |
7 H |
| Y3/8 |
Fully integrated transmission control control unit |
15 L |
| Z7/36z2 |
Circuit 87M2e connector sleeve |
7 L |
