| F16 |
Special protection vehicle additional fuse holder |
3L |
| F7 |
Fuse box I, rear |
4A |
| F7 |
Fuse box I, rear |
12A |
| F7 |
Fuse box I, rear |
20A |
| F7f1 |
Fuse 1 |
10B |
| F7f10 |
Fuse 10 |
21B |
| F7f2 |
Fuse 2 |
11B |
| F7f3 |
Fuse 3 |
13B |
| F7f4 |
Fuse 4 |
7B |
| F7f5 |
Fuse 5 |
8B |
| F7f6 |
Fuse 6 |
14B |
| F7f7 |
Fuse 7 |
17B |
| F7f8 |
Fuse 8 |
19B |
| F7f9 |
Fuse 9 |
20B |
| F8 |
Fuse box II, rear |
22L |
| K100 |
Circuit 15 two-way radio/feed-in relay carrier |
17L |
| K100 |
Circuit 15 two-way radio/feed-in relay carrier |
19L |
| K43 |
Two-way radio relay |
19L |
| K50 |
Circuit 15 feed relay |
17L |
| N100 |
Fire extinguishing system control unit |
14L |
| N26/14 |
Special vehicle multifunction control unit (SVMCU [MSS]) |
8L |
| S34/1 |
Two-way radio main switch |
10L |
| X58/2 |
Two-way radio switch-on connector |
11E |
| Z7/40z1 |
Tml. 30 connector sleeve |
21E |
| Z7/40z2 |
Tml. 30 connector sleeve |
8E |
| Z7/40z3 |
Tml. 30 connector sleeve |
6G |
| Z7/40z8 |
Tml. 30 connector sleeve |
12G |
| Z7/40z8 |
Tml. 30 connector sleeve |
15G |
