| A1 |
Instrument cluster |
12 G |
| A7/7 |
BAS brake booster |
13 A |
| A72 |
Rear door locking unit |
22 K |
| A9/1 |
AIRmatic compressor unit |
9 J |
| B22/10 |
Right rear level sensor |
5 J |
| B22/7 |
Left rear level sensor |
5 H |
| B22/8 |
Left front level sensor |
5 H |
| B22/9 |
Right front level sensor |
5 H |
| B24/3 |
Left front body lateral acceleration sensor |
6 K |
| B24/4 |
Right front body lateral acceleration sensor |
6 L |
| B24/6 |
Right rear body lateral acceleration sensor |
9 L |
| L6/1 |
Left front wheel speed sensor |
17 C |
| L6/2 |
Right front wheel speed sensor |
17 C |
| L6/3 |
Left rear wheel speed sensor |
17 D |
| L6/4 |
Right rear wheel speed sensor |
17 D |
| M14/5 |
Right front door CL motor |
22 K |
| M14/6 |
Driver door CL motor |
22 K |
| M14/8 |
Left rear door CL motor |
22 L |
| M14/9 |
Right rear door CL motor |
22 L |
| N10 |
Front SAM control unit |
18 J |
| N10/8 |
Rear SAM control module |
20 J |
| N3/9 |
CDI control module |
7 C |
| N47-5 |
ESP control module |
14 B |
| N49 |
Steering angle sensor |
10 B |
| N51 |
Airmatic control unit |
7 G |
| N71 |
Headlamp range adjustment control module |
15 G |
| N72 |
Lower control field control module |
20 B |
| N72/1 |
Upper control panel control module |
20 E |
| N72/1s2 |
Level adjustment switch |
22 E |
| N72/1s31 |
Comfort/Sport switch (ADS) |
22 F |
| N72s32 |
Level adjustment high switch |
20 B |
| N72s33 |
Level adjustment low switch |
20 B |
| N80 |
Steering column module |
10 C |
| N93 |
Central gateway control module |
18 E |
| U127 |
Valid for engine 272, engine 273 KE |
1 A |
| U151 |
Valid for engine 113 |
3 A |
| U152 |
Valid for engine 156 |
1 B |
| U152 |
Valid for engine 156 |
8 K |
| U153 |
Valid for all except engine 156 |
8 K |
| U475 |
Valid for M 272 |
6 B |
| U506 |
Valid for ADS |
6 K |
| U506 |
Valid for ADS |
22 E |
| U552 |
Valid for offroad package |
19 B |
| U557 |
Not valid for offroad package |
22 D |
| U880 |
Valid for engine 642 |
6 A |
| Y36 |
AIRmatic valve unit |
9 K |
| Y51 |
Left front axle damping valve unit |
7 K |
| Y52 |
Right front axle damping valve unit |
7 L |
| Y53 |
Left rear axle damping valve unit |
7 L |
| Y54 |
Right rear axle damping valve unit |
7 L |
