| A0 |
Color code key |
23L |
| F4 |
Load compartment fuse and relay box |
3L |
| F4f48 |
Fuse 48 |
4K |
| F4f52 |
Fuse 52 |
5K |
| F4f69 |
Fuse 69 |
2J |
| M70 |
Rear axle differential actuator motor |
14L |
| M70x1 |
Rear axle differential actuator motor connector |
12K |
| M70x2 |
Rear axle differential actuator motor connector |
16K |
| N15/9 |
Rear axle differential lock control unit |
4A |
| N15/9 |
Rear axle differential lock control unit |
12A |
| N15/9 |
Rear axle differential lock control unit |
20A |
| U154 |
Valid for 164.1 |
6C |
| U155 |
Valid for 164.8 |
6C |
| U155 |
Valid for 164.8 |
6D |
| W6/6 |
Ground (left spare tire well) |
7E |
| W62 |
Ground (left rear longitudinal member) |
7E |
| W7/7 |
Ground (right spare tire well) |
7K |
