| 1 |
Lock/unlock central locking, request |
3 G |
| 1 |
Lock/unlock central locking, request |
9 B |
| 1 |
Lock/unlock central locking, request |
14 J |
| 1 |
Lock/unlock central locking, request |
14 F |
| 1 |
Lock/unlock central locking, request |
19 K |
| 1 |
Lock/unlock central locking, request |
19 H |
| 2 |
Access authorization code, signal |
3 G |
| 2 |
Access authorization code, signal |
8 B |
| 2 |
Access authorization code, signal |
14 J |
| 2 |
Access authorization code, signal |
14 F |
| 2 |
Access authorization code, signal |
19 K |
| 2 |
Access authorization code, signal |
19 H |
| 3 |
Open/close central locking, request |
16 C |
| 3 |
Open/close central locking, request |
17 K |
| 3 |
Open/close central locking, request |
17 G |
| 3 |
Open/close central locking, request |
21 G |
| 4 |
CL [ZV] motor, actuation |
9 L |
| 4 |
CL [ZV] motor, actuation |
17 A |
| 4 |
CL [ZV] motor, actuation |
18 E |
| 4 |
CL [ZV] motor, actuation |
21 D |
| 5 |
Visual feedback, request |
17 G |
| 6 |
Flasher frequency, signal |
16 H |
| 6 |
Flasher frequency, signal |
16 C |
| 6 |
Flasher frequency, signal |
19 E |
| 7 |
Turn signal lamp, actuation |
1 J |
| 7 |
Turn signal lamp, actuation |
6 J |
| 7 |
Turn signal lamp, actuation |
7 F |
| 7 |
Turn signal lamp, actuation |
12 F |
| 7 |
Turn signal lamp, actuation |
22 K |
| 7 |
Turn signal lamp, actuation |
27 K |
| A2/93 |
Roof antenna module |
9 C |
| A26/1 |
Left front IR receiver |
2 H |
| A8/1 |
Transmitter key |
2 C |
| CAN B |
Interior CAN |
15 H |
| CAN B |
Interior CAN |
15 D |
| CAN B |
Interior CAN |
18 F |
| CAN B |
Interior CAN |
18 K |
| CAN B |
Interior CAN |
18 H |
| CAN B |
Interior CAN |
20 H |
| E1e5 |
Left turn signal lamp |
27 K |
| E2e5 |
Right turn signal lamp |
23 K |
| E3e1 |
Left turn signal lamp |
7 E |
| E4e1 |
Right turn signal lamp |
12 E |
| E6/5 |
Left exterior mirror turn signal lamp |
5 K |
| E6/6 |
Right exterior mirror turn signal lamp |
1 K |
| M14/10 |
Fuel filler flap CL motor |
17 D |
| M14/5 |
Right front door CL motor |
18 B |
| M14/6 |
Driver door CL motor |
8 L |
| M14/8 |
Left rear door CL motor |
21 C |
| M14/9 |
Right rear door CL motor |
17 D |
| N10 |
Front SAM control unit |
21 E |
| N10/8 |
Rear SAM control module |
15 E |
| N69/1 |
Left front door control module |
15 J |
| N69/2 |
Right front door control module |
15 A |
| N73 |
EIS [EZS] control unit |
21 J |
