| A2/53 |
Telephone/portable CTEL/STH radio remote control antenna splitter |
16L |
| A2/91 |
Bluetooth antenna |
47L |
| A2/93 |
Roof antenna module |
12L |
| A2/93 |
Roof antenna module |
14L |
| A28/3 |
E-net compensator |
9L |
| A34/15 |
UHI portable CTEL holder (Universal Handy Interface) |
29L |
| A34/15x1 |
Connector 1, UPCI [UHI] portable CTEL holder (Universal Interface) Handy |
28K |
| A34/15x2 |
Connector 2, UPCI [UHI] portable CTEL holder (Universal Interface) Handy |
26K |
| A6/1 |
STH radio remote control receiver |
20L |
| A67b1 |
Hands-free system microphone group |
38L |
| A67b1 |
Hands-free system microphone group |
42L |
| A67b1x1 |
Hands-free system microphone group connector |
37J |
| A67b1x1 |
Hands-free system microphone group connector |
41J |
| F4 |
Load compartment fuse and relay box |
3L |
| F4f23 |
Fuse 23 |
3L |
| MOST |
Media Oriented System Transport |
45B |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
4A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
12A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
20A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
28A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
35A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
44A |
| U3 |
Valid for all except Japan |
37A |
| U434 |
Not valid for VCS [SBS] |
36A |
| U434 |
Not valid for VCS [SBS] |
40A |
| U579 |
Valid for stationary heater |
13G |
| U580 |
Valid without stationary heater |
11G |
| U78 |
Valid for Japan |
41A |
| W17/1 |
Ground (left rear seat) |
6H |
| X18/2 |
Interior/roof connector |
37E |
| X18/2 |
Interior/roof connector |
40E |
| X29/6 |
Center console intermediate connector |
24F |
| X29/6 |
Center console intermediate connector |
23F |
| X29/6 |
Center console intermediate connector |
26F |
| Z204/6 |
Circuit 31 left rear seat voltage distributor connector |
6L |
| Z53/25 |
UPCI [UHI] circuit 30 interior compartment solder point |
2E |
| Z53/26 |
Telematics circuit 31 interior solder point 1 |
8E |
