| A1 |
Instrument cluster |
34 L |
| F4 |
Load compartment fuse and relay box |
4 A |
| F4 |
Load compartment fuse and relay box |
13 A |
| F4 |
Load compartment fuse and relay box |
21 A |
| F4 |
Load compartment fuse and relay box |
29 A |
| F4 |
Load compartment fuse and relay box |
37 A |
| F4 |
Load compartment fuse and relay box |
45 A |
| F4 |
Load compartment fuse and relay box |
53 A |
| F4 |
Load compartment fuse and relay box |
61 A |
| F4f27 |
Fuse 27 |
54 A |
| F4f28 |
Fuse 28 |
51 A |
| F4f31 |
Fuse 31 |
39 A |
| F4f32 |
Fuse 32 |
18 A |
| F4f35 |
Fuse 35 |
26 A |
| F4f36 |
Fuse 36 |
30 A |
| F4f49 |
Fuse 49 |
11 A |
| F4f53 |
Fuse 53 |
22 A |
| F4f55 |
Fuse 55 |
32 A |
| F4f58 |
Fuse 58 |
43 A |
| F4f59 |
Fuse 59 |
3 A |
| F4f64 |
Fuse 64 |
56 A |
| F4f65 |
Fuse 65 |
59 A |
| F4f66 |
Fuse 66 |
7 D |
| F4f70 |
Fuse 70 |
4 D |
| F4f72 |
Fuse 72 |
5 D |
| F4kL |
Trailer circuit 30X relay |
6 A |
| F4kM |
Heated rear window relay |
10 A |
| F4kS |
Circuit 15 relay (2) |
58 A |
| F4kT |
Spare 2 (normally open contact) |
60 A |
| K24/1 |
Driver seat adjustment comfort relay |
54 L |
| K24/2 |
Front passenger seat adjustment comfort relay |
56 L |
| L13/1 |
Right antenna coil |
12 L |
| L13/3 |
Left antenna coil (2) |
15 L |
| L13/4 |
Left antenna coil (1) |
16 L |
| M40 |
Multicontour seat pneumatic pump |
7 L |
| N10/8 |
Rear SAM control unit |
10 L |
| N123/4 |
Emergency call system control unit |
30 L |
| N15/7 |
Transfer case control unit |
22 L |
| N25/7 |
HS [SIH], seat ventilation and steering wheel heater control unit |
39 L |
| N32/1 |
Driver front seat adjustment control unit with memory |
48 L |
| N32/2 |
Front passenger front seat adjustment control unit with memory |
51 L |
| N40/3 |
Amplifier for sound system |
26 L |
| N51 |
AIRMATIC control unit |
19 L |
| N93 |
Central gateway control unit |
43 L |
| R1 |
Heated rear window |
14 L |
| S1 |
Rotary light switch |
36 L |
| U502 |
Valid for AIRMATIC |
17 F |
| U541 |
Valid for TELE AID emergency call system |
28 F |
| U552 |
Valid for offroad package |
21 F |
| U63 |
Valid for seat adjustment without memory |
53 F |
| U71 |
Valid for seat adjustment with memory |
46 F |
| U744 |
Valid for steering wheel heater |
37 F |
| U749 |
Valid for multicontour seat (MCS [MKS]) |
6 F |
| U831 |
Valid for crash-active head restraints |
1 F |
| W8/1 |
Ground (left rear-end door) |
16 E |
| X11/4 |
Data link connector |
45 L |
| X18 |
Interior/cockpit connector |
32 H |
| X55/3 |
Left front seat contacting strip |
1 H |
| X55/3 |
Left front seat contacting strip |
54 H |
| X55/4 |
Right front seat contacting strip |
3 H |
| X55/4 |
Right front seat contacting strip |
55 H |
| Y24/12 |
Driver NECK-PRO head restraint solenoid |
2 L |
| Y24/12x1 |
Driver NECK-PRO head restraint solenoid connector |
1 K |
| Y24/13 |
Front passenger NECK-PRO head restraint solenoid |
4 L |
| Y24/13x1 |
Front passenger NECK-PRO head restraint solenoid connector |
4 K |
| Z3/11 |
Circuit 15 (fused) connector sleeve |
34 H |
| Z43 |
Heated rear window connector sleeve |
16 H |
| Z53/20 |
Interior connector sleeve, 15R |
2 L |
