Electrical function diagram for compass module - PE54.30-U-2052-99MAA

Code:	Designation:	Position:
A1	Instrument cluster	8 C
B26	Electronic compass	14 F
N10	Front SAM control unit	8 H
N10/8	Rear SAM control module	11 H
N70	Overhead control panel control module	5 B
N73	DI control module	5 H
N93	Central gateway control module	2 F

Fig 1: Compass Module Electrical Function Diagram

Courtesy of MERCEDES-BENZ USA
