| A72 |
Rear door locking unit |
19 L |
| A72 |
Rear door locking unit |
26 L |
| B51/5 |
Left vent window obstruction sensor strip |
4 L |
| B51/5x1 |
Left vent window obstruction sensor strip connector |
3 J |
| B51/6 |
Right vent window obstruction sensor strip |
8 L |
| B51/6x1 |
Right vent window obstruction sensor strip connector |
8 J |
| E17/43 |
Left front door ambiance illumination |
31 L |
| E17/43 |
Left front door ambiance illumination |
42 L |
| E17/44 |
Right front door ambiance illumination |
33 L |
| E17/44 |
Right front door ambiance illumination |
44 L |
| E17/45 |
Left rear door ambiance illumination |
35 L |
| E17/45 |
Left rear door ambiance illumination |
45 L |
| E17/46 |
Right rear door ambiance illumination |
37 L |
| E17/46 |
Right rear door ambiance illumination |
47 L |
| M21/8 |
Left vent window motor |
1 L |
| M21/9 |
Right vent window motor |
2 L |
| N10/8 |
Rear SAM control unit |
4 A |
| N10/8 |
Rear SAM control unit |
13 A |
| N10/8 |
Rear SAM control unit |
20 A |
| N10/8 |
Rear SAM control unit |
28 A |
| N10/8 |
Rear SAM control unit |
36 A |
| N10/8 |
Rear SAM control unit |
44 A |
| N10/8 |
Rear SAM control unit |
52 A |
| S133/1 |
Fuel filler flap switch |
15 L |
| S133/1x1 |
Fuel filler flap switch electrical connector |
14 J |
| S150 |
Loading floor switch |
12 L |
| S159/1 |
Right easy entry feature microswitch, 2nd seat row |
10 L |
| S159/1x1 |
Right easy entry feature microswitch connector, 2nd seat row |
10 K |
| S88/9 |
Rear-end door handle switch |
22 L |
| S88/9 |
Rear-end door handle switch |
29 L |
| U154 |
Valid for 164.1 |
16 A |
| U154 |
Valid for 164.1 |
23 A |
| U154 |
Valid for 164.1 |
49 G |
| U155 |
Valid for 164.8 |
10 A |
| U155 |
Valid for 164.8 |
16 A |
| U155 |
Valid for 164.8 |
49 G |
| U156 |
Valid for electric vent window |
1 A |
| U884 |
Valid for ambiance illumination |
30 A |
| U978 |
Valid for full hybrid drive |
12 A |
| W17 |
Ground (right rear seat) |
13 H |
| W17/1 |
Ground (left rear seat) |
50 H |
| W29/9 |
Ground (right D-pillar) |
22 H |
| W29/9 |
Ground (right D-pillar) |
29 H |
| W6 |
Ground (left wheelhouse in luggage compartment) |
6 H |
| W6 |
Ground (left wheelhouse in luggage compartment) |
12 G |
| W7 |
Ground (right wheelhouse in luggage compartment) |
6 H |
| W7 |
Ground (right wheelhouse in luggage compartment) |
40 H |
| W7 |
Ground (right wheelhouse in luggage compartment) |
50 G |
| W8 |
Ground (rear-end door) |
22 E |
| W8 |
Ground (rear-end door) |
29 G |
| X157/10 |
Right rear door trim strip illumination separating point |
46 J |
| X157/6 |
Right front door trim strip illumination separating point |
43 J |
| X157/7 |
Left front door trim strip illumination separating point |
41 J |
| X157/8 |
Instrument panel ambiance illumination connecting point |
39 L |
| X157/8 |
Instrument panel ambiance illumination connecting point |
51 L |
| X157/9 |
Left rear door trim strip illumination separating point |
44 J |
| X18 |
Interior/cockpit connector |
38 H |
| X18 |
Interior/cockpit connector |
51 H |
| X213 |
Rear SAM connecting point |
23 E |
| X35/1 |
Left front door separation point |
30 H |
| X35/1 |
Left front door separation point |
41 G |
| X35/2 |
Right front door separation point |
32 H |
| X35/2 |
Right front door separation point |
43 G |
| X35/3 |
Left rear door separation point |
34 H |
| X35/3 |
Left rear door separation point |
45 G |
| X35/4 |
Right rear door separation point |
36 H |
| X35/4 |
Right rear door separation point |
46 G |
| X55/6 |
Right rear seat adjustment connector block |
10 E |
| Z204/1 |
Circuit 31 left wheelhouse luggage compartment voltage distributor connector |
5 L |
| Z204/2 |
Circuit 31 right wheelhouse luggage compartment voltage distributor connector |
7 L |
| Z204/2 |
Circuit 31 right wheelhouse luggage compartment voltage distributor connector |
40 L |
| Z204/2 |
Circuit 31 right wheelhouse luggage compartment voltage distributor connector |
50 L |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
13 L |
| Z204/6 |
Circuit 31 left rear seat voltage distributor connector |
50 L |
| Z232 |
Ambiance illumination connector sleeve |
33 E |
| Z232 |
Ambiance illumination connector sleeve |
43 D |
| Z232/1 |
Ambiance illumination circuit 31 connector sleeve |
37 E |
| Z232/1 |
Ambiance illumination circuit 31 connector sleeve |
47 E |
| Z55/1 |
Rear-end door circuit 31 connector sleeve |
21 H |
| Z55/1 |
Rear-end door circuit 31 connector sleeve |
28 J |
