| A49/6 |
Radio antenna interference filter |
19 M |
| A49/6x1 |
Radio antenna interference suppression filter electrical connector |
19 L |
| CAN B |
Interior CAN |
5 L |
| E15/9 |
Right load compartment dome lamp |
35 M |
| E17/27 |
Rear-end door warning lamp |
72 M |
| E17/5 |
Left rear door entrance/exit lamp |
37 M |
| E17/6 |
Right rear door entrance/exit lamp |
42 M |
| E19/3 |
Left rear-end door license plate lamp |
74 M |
| E19/4 |
Right rear-end door license plate lamp |
76 M |
| E21 |
Center high-mounted stop lamp |
78 M |
| E3 |
Left tail lamp |
53 M |
| E3e1 |
Left turn signal lamp |
56 M |
| E3e1 |
Left turn signal lamp |
56 M |
| E3e10 |
Left brake light and taillight |
56 M |
| E3e2 |
Left tail lamp and rear fog lamp |
54 M |
| E3e2 |
Left tail lamp and rear fog lamp |
54 M |
| E3e3 |
Left backup lamp |
54 M |
| E3e3 |
Left backup lamp |
54 M |
| E3e4 |
Left stop lamp |
56 M |
| E3e8 |
Left tail lamp, side-marker lamp, parking lamp |
55 M |
| E3e9 |
Left stop lamp, tail lamp, parking lamp and side-marker lamp |
55 M |
| E4 |
Right tail lamp |
60 M |
| E40/1 |
Rear-end door ambient lamp |
69 M |
| E40/1 |
Rear-end door ambient lamp |
71 M |
| E4e1 |
Right turn signal lamp |
58 M |
| E4e1 |
Right turn signal lamp |
58 M |
| E4e10 |
Right brake light and taillight |
57 M |
| E4e2 |
Right tail lamp and rear fog lamp |
59 M |
| E4e2 |
Right tail lamp and rear fog lamp |
59 M |
| E4e3 |
Right backup lamp |
58 M |
| E4e3 |
Right backup lamp |
58 M |
| E4e4 |
Right stop lamp |
57 M |
| E4e8 |
Right tail lamp, side-marker lamp, parking lamp |
59 M |
| E4e9 |
Right stop lamp, tail lamp, parking lamp and side-marker lamp |
59 M |
| F33 |
Battery compartment prefuse box |
2 M |
| F33f79 |
Fuse 79 |
1 L |
| F33f80 |
Fuse 80 |
3 L |
| F4 |
Load compartment fuse and relay box |
17 M |
| F58 |
Engine compartment fuse and relay box |
31 M |
| F58f110 |
Fuse 110 |
29 M |
| H3 |
Alarm signal horn |
67 M |
| H3/1 |
Alarm signal siren |
33 M |
| K24/2 |
Front passenger seat adjustment comfort relay |
11 M |
| N10/8 |
Rear SAM control unit |
4 B |
| N10/8 |
Rear SAM control unit |
12 B |
| N10/8 |
Rear SAM control unit |
20 B |
| N10/8 |
Rear SAM control unit |
28 B |
| N10/8 |
Rear SAM control unit |
36 B |
| N10/8 |
Rear SAM control unit |
44 B |
| N10/8 |
Rear SAM control unit |
52 B |
| N10/8 |
Rear SAM control unit |
60 B |
| N10/8 |
Rear SAM control unit |
68 B |
| N10/8 |
Rear SAM control unit |
76 B |
| N30/6 |
Regenerative braking system control unit |
26 M |
| N47-5 |
ESP control unit |
26 M |
| N70 |
Overhead control panel control unit |
9 M |
| U1 |
Valid for {{USA}} |
65 D |
| U151 |
Valid for engine 113 |
27 F |
| U151 |
Valid for engine 113 |
31 E |
| U151 |
Valid for engine 113 |
65 F |
| U154 |
Valid for 164.1 |
1 D |
| U154 |
Valid for 164.1 |
4 E |
| U154 |
Valid for 164.1 |
44 J |
| U154 |
Valid for 164.1 |
53 J |
| U154 |
Valid for 164.1 |
60 K |
| U154 |
Valid for 164.1 |
73 D |
| U154 |
Valid for 164.1 |
75 D |
| U155 |
Valid for 164.8 |
1 D |
| U155 |
Valid for 164.8 |
4 F |
| U155 |
Valid for 164.8 |
48 J |
| U155 |
Valid for 164.8 |
53 J |
| U155 |
Valid for 164.8 |
62 K |
| U155 |
Valid for 164.8 |
73 D |
| U182 |
Valid without spare tire carrier |
55 J |
| U182 |
Valid without spare tire carrier |
73 G |
| U2 |
Valid for all except {{USA}} |
29 D |
| U63 |
Valid for seat adjustment without memory |
11 E |
| U656 |
Valid for interior light package |
68 G |
| U681 |
Valid for all except M113 |
25 F |
| U681 |
Valid for all except M113 |
31 F |
| U681 |
Valid for all except M113 |
65 F |
| U805 |
Not valid on vehicles with automatic rear-end door or loading floor |
70 G |
| U899 |
Valid for backup camera |
49 J |
| U899 |
Valid for backup camera |
49 J |
| U932 |
Valid for engine 642 BLUETEC |
20 J |
| U974 |
Not valid for full hybrid drive |
24 L |
| U978 |
Valid for full hybrid drive |
20 J |
| U978 |
Valid for full hybrid drive |
24 L |
| U981 |
Not valid for 642 BlueTEC and full hybrid drive |
20 H |
| W15/2 |
Ground (left footwell) |
41 J |
| W16/3 |
Ground (left assembly compartment, power ground) |
34 M |
| W16/3 |
Ground (left assembly compartment, power ground) |
67 M |
| W17 |
Ground (right rear seat) |
2 F |
| W17 |
Ground (right rear seat) |
45 M |
| W29/9 |
Ground (right D-pillar) |
77 M |
| W6 |
Ground (left wheelhouse in luggage compartment) |
53 F |
| W7 |
Ground (right wheelhouse in luggage compartment) |
2 F |
| W7 |
Ground (right wheelhouse in luggage compartment) |
35 J |
| W7 |
Ground (right wheelhouse in luggage compartment) |
62 M |
| W8 |
Ground (rear-end door) |
70 J |
| W8 |
Ground (rear-end door) |
71 J |
| W8 |
Ground (rear-end door) |
78 H |
| X18/2 |
Interior/roof connector |
8 J |
| X18/3 |
Interior/fuel tank connector |
21 G |
| X213 |
Rear SAM connecting point |
76 F |
| X25/2 |
Engine compartment/interior compartment connector |
25 J |
| X25/2 |
Engine compartment/interior compartment connector |
27 J |
| X25/2 |
Engine compartment/interior compartment connector |
31 G |
| X25/2 |
Engine compartment/interior compartment connector |
33 G |
| X25/2 |
Engine compartment/interior compartment connector |
65 H |
| X25/2 |
Engine compartment/interior compartment connector |
67 H |
| X30/4 |
Right voltage distributor (CAN) connector |
5 M |
| X30/5 |
Left voltage distributor (CAN) connector |
5 M |
| X35/3 |
Left rear door separation point |
36 F |
| X35/4 |
Right rear door separation point |
41 F |
| X55/4 |
Right front seat contacting strip |
11 J |
| X8/16 |
Left rear door printed wiring harness connector |
36 J |
| X8/17 |
Right rear door printed wiring harness connector |
41 J |
| Z204/2 |
Circuit 31 right wheelhouse luggage compartment voltage distributor connector |
64 M |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
47 M |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
48 M |
| Z204/5 |
Circuit 31 left footwell voltage distributor connector (1) |
40 M |
| Z204/7 |
Circuit 31 left footwell voltage distributor connector (2) |
40 M |
| Z50/5 |
Tml. 15 connector sleeve |
17 F |
| Z55/1 |
Rear-end door circuit 31 connector sleeve |
77 M |
| Z55/4 |
Rear-end door warning lamp terminal connector |
72 J |
| Z6/12 |
Left rear door ground connector sleeve |
38 M |
| Z6/13 |
Right rear door ground connector sleeve |
43 M |
