| A1 |
Instrument cluster |
6 L |
| A100 |
High-voltage battery module |
2 L |
| A100 |
High-voltage battery module |
77 L |
| A100x1 |
Electrical connector for high-voltage battery module with interlock circuit |
2 J |
| A100x1 |
Electrical connector for high-voltage battery module with interlock circuit |
76 J |
| A76 |
Left front reversible emergency tensioning retractor |
10 L |
| A76/1 |
Right front reversible emergency tensioning retractor |
11 L |
| F4 |
Load compartment fuse and relay box |
4 A |
| F4 |
Load compartment fuse and relay box |
11 A |
| F4 |
Load compartment fuse and relay box |
20 A |
| F4 |
Load compartment fuse and relay box |
28 A |
| F4 |
Load compartment fuse and relay box |
36 A |
| F4 |
Load compartment fuse and relay box |
44 A |
| F4 |
Load compartment fuse and relay box |
52 A |
| F4 |
Load compartment fuse and relay box |
61 A |
| F4 |
Load compartment fuse and relay box |
69 A |
| F4 |
Load compartment fuse and relay box |
76 A |
| F4f30 |
Fuse 30 |
43 A |
| F4f32 |
Fuse 32 |
27 A |
| F4f38 |
Fuse 38 |
3 A |
| F4f40 |
Fuse 40 |
23 A |
| F4f43 |
Fuse 43 |
32 A |
| F4f46 |
Fuse 46 |
68 A |
| F4f47 |
Fuse 47 |
75 A |
| F4f48 |
Fuse 48 |
14 A |
| F4f51 |
Fuse 51 |
60 A |
| F4f52 |
Fuse 52 |
12 A |
| F4f53 |
Fuse 53 |
42 A |
| F4f54 |
Fuse 54 |
65 A |
| F4f55 |
Fuse 55 |
6 A |
| F4f59 |
Fuse 59 |
57 A |
| F4f61 |
Fuse 61 |
54 A |
| F4f64 |
Fuse 64 |
47 A |
| F4f65 |
Fuse 65 |
50 A |
| F4kV |
Backup relay 2 |
49 A |
| K88 |
Pyrotechnical separator |
20 L |
| K88x1 |
Pyrotechnical separator electrical connector |
20 H |
| M43/2 |
High-voltage battery coolant pump |
74 L |
| N10 |
Front SAM control unit |
66 L |
| N118/3 |
Left fuel pump control unit |
42 L |
| N118/4 |
Right fuel pump control unit |
46 L |
| N121/1 |
Rear-end door closing control unit |
24 L |
| N15/7 |
Transfer case control unit |
39 L |
| N15/9 |
Rear axle differential lock control unit |
13 L |
| N17 |
Illuminated door sill molding actuation module LED |
72 L |
| N2/7 |
Restraint systems control unit |
54 L |
| N32/26 |
Folding rear bench seat control unit |
50 L |
| N51 |
AIRMATIC control unit |
28 L |
| N71 |
Headlamp range adjustment control unit |
62 L |
| R3 |
Front cigar lighter (with ashtray illumination) |
69 L |
| R3r1 |
Heating element |
69 L |
| R3x1 |
Front cigar lighter (with ashtray illumination) connector |
68 K |
| S1 |
Rotary light switch |
8 L |
| U127 |
Valid for engine 272, engine 273 KE |
30 F |
| U127 |
Valid for engine 272, engine 273 KE |
34 F |
| U127 |
Valid for engine 272, engine 273 KE |
59 F |
| U151 |
Valid for engine 113 |
59 G |
| U152 |
Valid for engine 156 |
41 F |
| U501 |
Valid for xenon headlamps |
61 F |
| U502 |
Valid for AIRMATIC |
26 F |
| U552 |
Valid for offroad package |
12 F |
| U552 |
Valid for offroad package |
37 F |
| U664 |
Valid for automatic rear-end door |
23 F |
| U715 |
Valid for illuminated door sills |
70 G |
| U775 |
Valid for reversible emergency tensioning retractor |
9 F |
| U831 |
Valid for crash-active head restraints |
56 F |
| U881 |
Valid for 3rd rear seat |
48 F |
| U932 |
Valid for engine 642 BLUETEC |
15 F |
| U978 |
Valid for full hybrid drive |
1 G |
| U978 |
Valid for full hybrid drive |
19 F |
| U978 |
Valid for full hybrid drive |
30 G |
| U978 |
Valid for full hybrid drive |
74 F |
| X18 |
Interior/cockpit connector |
5 H |
| X29/6 |
Center console intermediate connector |
68 H |
| X55/3 |
Left front seat contacting strip |
56 H |
| X55/4 |
Right front seat contacting strip |
57 H |
| Y24/12 |
Driver NECK-PRO head restraint solenoid |
56 L |
| Y24/12x1 |
Driver NECK-PRO head restraint solenoid connector |
56 K |
| Y24/13 |
Front passenger NECK-PRO head restraint solenoid |
57 L |
| Y24/13x1 |
Front passenger NECK-PRO head restraint solenoid connector |
57 K |
| Y58/4 |
Activated charcoal filter shutoff valve |
59 L |
| Z3/11 |
Circuit 15 (fused) connector sleeve |
6 H |
| Z7/88 |
Fuel pump control unit circuit 30 connector sleeve |
43 H |
