| A0 |
Color code key |
80L |
| Code 494 |
USA version |
61F |
| Code B03 |
ECO start/stop function |
1J |
| E1 |
Left front lamp unit |
6K |
| E1b1 |
Left active curve illumination position sensor |
21G |
| E1b2 |
Left light distribution position sensor |
23G |
| E1e10 |
Left xenon bulb with integrated ignition module |
30G |
| E1e3 |
Left front standing and parking lamp |
19G |
| E1e5 |
Left front turn signal lamp |
18G |
| E1e9 |
Left cornering illumination |
16G |
| E1m1 |
Left headlamp range adjustment actuator motor |
26G |
| E1m2 |
Left active curve illumination actuator motor |
22G |
| E1m3 |
Left light distribution actuator motor |
24G |
| E1n4 |
Left xenon light power supply module |
29L |
| E1n7 |
Actuation module for left front exterior lights LED |
13L |
| E1n7 |
Actuation module for left front exterior lights LED |
20L |
| E2 |
Right front lamp unit |
36K |
| E2b1 |
Right active curve illumination position sensor |
51G |
| E2b2 |
Right light distribution position sensor |
53G |
| E2e10 |
Right xenon bulb with integrated ignition module |
59G |
| E2e3 |
Right front standing and parking lamp |
49G |
| E2e5 |
Right front turn signal lamp |
47G |
| E2e9 |
Right cornering illumination |
46G |
| E2m1 |
Right headlamp range adjustment actuator motor |
56G |
| E2m2 |
Right active curve illumination actuator motor |
52G |
| E2m3 |
Right light distribution actuator motor |
54G |
| E2n4 |
Right xenon light power supply module |
58L |
| E2n7 |
Actuation module for right front exterior lights LED |
38L |
| E2n7 |
Actuation module for right front exterior lights LED |
45L |
| E6/1 |
Left front side-marker lamp |
61L |
| E6/2 |
Right front side-marker lamp |
63L |
| LIN G1 |
Left headlamp LIN |
15H |
| LIN G1 |
Left headlamp LIN |
22K |
| LIN G1 |
Left headlamp LIN |
28K |
| LIN G1 |
Left headlamp LIN |
18K |
| LIN G1 |
Left headlamp LIN |
51K |
| LIN G1 |
Left headlamp LIN |
57K |
| LIN G2 |
Right headlamp LIN |
39H |
| LIN G2 |
Right headlamp LIN |
47K |
| N10/1 |
Front SAM control unit with fuse and relay module |
4A |
| N10/1 |
Front SAM control unit with fuse and relay module |
11A |
| N10/1 |
Front SAM control unit with fuse and relay module |
28A |
| N10/1 |
Front SAM control unit with fuse and relay module |
20A |
| N10/1 |
Front SAM control unit with fuse and relay module |
36A |
| N10/1 |
Front SAM control unit with fuse and relay module |
45A |
| N10/1 |
Front SAM control unit with fuse and relay module |
52A |
| N10/1 |
Front SAM control unit with fuse and relay module |
60A |
| N10/1 |
Front SAM control unit with fuse and relay module |
68A |
| N10/1f29 |
Fuse 29 |
44A |
| N10/1f30 |
Fuse 30 |
15A |
| N10/1f5 |
Fuse 5 |
65A |
| N10/1kJ |
Circuit 15 relay |
13A |
| S1 |
Exterior lights switch |
67L |
| S1e4 |
Switch illumination |
67L |
| S1s10 |
Rear fog light button |
66K |
| S1s11 |
Front fog lamp button |
66J |
| U240 |
Valid for all except ECO start/stop function |
1J |
| U255 |
Valid for front fog lamps |
8G |
| U57 |
Valid for model 204.2 |
4H |
| U57 |
Valid for model 204.2 |
34H |
| U58 |
Valid for model 204.0 |
4H |
| U58 |
Valid for model 204.0 |
34H |
| U59 |
Valid for model 204.9 |
4J |
| U59 |
Valid for model 204.9 |
34J |
| U60 |
Valid for model 204.3 |
4J |
| U60 |
Valid for model 204.3 |
34J |
| U971 |
Valid for daytime running lamps |
8G |
| W16/3 |
Left major assembly compartment ground point |
61H |
| W16/4 |
Right wheelhouse ground point |
35L |
| W16/4 |
Right wheelhouse ground point |
62H |
| W9 |
Left front ground point (at lamp unit) |
5L |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
68G |
| Z50/1 |
Circuit 58d instrument panel connector sleeve |
70G |
