| F34 |
Interior fuse box |
L20 |
| F34f37 |
Fuse 37 |
K19 |
| K36 |
Longitudinal equalization differential lock relay module |
L18 |
| M40 |
Differential locks vacuum pump |
L16 |
| N10/1 |
Front signal acquisition and actuation module (SAM) |
L7 |
| N15/7 |
VGS control unit |
L32 |
| N30/4 |
ESP control unit |
L24 |
| N47-5 |
ESP and BAS control unit |
L24 |
| S1 |
Light switch module |
A2 |
| S76 |
Differential lock switch group |
A6 |
| S76 |
Differential lock switch group |
A12 |
| S76 |
Differential lock switch group |
A20 |
| S76 |
Differential lock switch group |
A28 |
| S76/7 |
Differential lock indicator switch (longitudinal equalization) |
L28 |
| S76/8 |
Rear axle differential lock indicator switch |
L21 |
| S76/9 |
Front axle differential lock indicator switch |
L29 |
| W10/8 |
Ground (right battery recess) |
G18 |
| W29/1 |
Ground (left A-pillar) |
G11 |
| W29/1 |
Ground (left A-pillar) |
G15 |
| W30 |
Ground (frame) |
G21 |
| W43 |
Ground (firewall) |
E7 |
| W43 |
Ground (firewall) |
E28 |
| X26/22 |
Cockpit/FSS (RBA) traction systems connector |
F23 |
| X35/6 |
Cockpit/module box separation point |
E5 |
| X35/6 |
Cockpit/module box separation point |
G10 |
| X35/6 |
Cockpit/module box separation point |
E11 |
| X35/6 |
Cockpit/module box separation point |
G23 |
| X35/6 |
Cockpit/module box separation point |
G23 |
| X35/6 |
Cockpit/module box separation point |
G30 |
| X62/18 |
Front axle differential lock connector (function indicator), 2 poles |
G27 |
| X92/3 |
Frame connector (22-pin) |
G20 |
| Y68 |
Differential lock solenoid valve (longitudinal equalization) |
L14 |
| Y68/1 |
Differential lock solenoid valve (rear axle) |
L13 |
| Y68/2 |
Differential lock solenoid valve (front axle) |
L12 |
| Z81/6 |
Circuit 58d connector sleeve |
G6 |
