| A45 |
Fanfare horns and airbag clock spring contact |
11J |
| A53 |
Left side airbag sensor |
24L |
| A54 |
Right side airbag sensor |
25L |
| B41/1 |
Front passenger seat occupied recognition |
43L |
| B48 |
Front passenger seat occupied recognition and automatic child seat recognition |
43L |
| B48/1 |
Left frontal acceleration sensor |
29L |
| B48/10 |
Right rear door pressure sensor |
79L |
| B48/2 |
Right frontal acceleration sensor |
30L |
| B48/7 |
Left front door pressure sensor |
26L |
| B48/8 |
Right front door pressure sensor |
28L |
| B48/9 |
Left rear door pressure sensor |
77L |
| CAN E |
Chassis CAN |
7K |
| F32 |
Front electrical prefuse box |
22L |
| N10/1 |
Front SAM control module with fuse and relay module |
3L |
| N10/1 |
Front SAM control module with fuse and relay module |
39L |
| N10/1f15 |
Fuse 15 |
1L |
| N10/1f8 |
Fuse 8 |
4L |
| N10/2 |
Rear SAM control module with fuse and relay module |
54L |
| N123/4 |
Emergency call system control unit |
74L |
| N2/10 |
Supplemental restraint system control unit |
3A |
| N2/10 |
Supplemental restraint system control unit |
12A |
| N2/10 |
Supplemental restraint system control unit |
20A |
| N2/10 |
Supplemental restraint system control unit |
27A |
| N2/10 |
Supplemental restraint system control unit |
36A |
| N2/10 |
Supplemental restraint system control unit |
44A |
| N2/10 |
Supplemental restraint system control unit |
52A |
| N2/10 |
Supplemental restraint system control unit |
60A |
| N2/10 |
Supplemental restraint system control unit |
68A |
| N2/10 |
Supplemental restraint system control unit |
76A |
| N80 |
Steering column module control unit |
11L |
| R12/1 |
Driver ETR [GUS] ignition squib |
72L |
| R12/10 |
Right side airbag ignition squib |
33L |
| R12/11 |
Left rear sidebag squib |
62L |
| R12/12 |
Right rear sidebag squib |
61L |
| R12/13 |
Driver airbag squib 1 |
14L |
| R12/14 |
Driver airbag squib 2 |
15L |
| R12/2 |
Front passenger ETR [GUS] squib |
70L |
| R12/22 |
Left window airbag ignition squib |
63L |
| R12/23 |
Right window airbag ignition squib |
65L |
| R12/25 |
Driver kneebag squib |
19L |
| R12/4 |
Front passenger airbag squib 1 |
16L |
| R12/5 |
Front passenger airbag squib 2 |
17L |
| R12/6 |
Left rear emergency tensioning retractor squib |
67L |
| R12/7 |
Right rear emergency tensioning retractor squib |
69L |
| R12/9 |
Driver side airbag squib |
35L |
| S68/14 |
Center rear seat belt buckle switch |
50L |
| S68/14x1 |
Center rear seat belt buckle switch electrical connector |
50J |
| S68/3 |
Driver seat belt buckle restraint system switch |
37L |
| S68/4 |
Front passenger seat belt buckle restraint system switch |
31L |
| S68/5 |
Left rear seat belt buckle switch |
49L |
| S68/5x1 |
Left rear seat belt buckle switch electrical connector |
49J |
| S68/6 |
Right rear seat belt buckle switch |
51L |
| S68/6x1 |
Right rear seat belt buckle switch electrical connector |
51J |
| U108 |
Valid for rear seat belt buckles |
49E |
| U12 |
Valid for left-hand steering |
33D |
| U12 |
Valid for left-hand steering |
41J |
| U13 |
Valid for right-hand steering |
33D |
| U13 |
Valid for right-hand steering |
41J |
| U2 |
Valid for all except USA |
41C |
| U233 |
Valid for kneebag |
18C |
| U541 |
Valid for TELEAID emergency call system |
73C |
| U596 |
Valid for rear side airbag |
60C |
| U596 |
Valid for rear side airbag |
77C |
| U775 |
Valid for emergency tensioning retractor |
66C |
| U848 |
Valid for ACSR |
42J |
| U859 |
Valid for seat belt reminder warning |
42J |
| V24 |
Driver overvoltage protection diode |
57L |
| V25 |
Front passenger overvoltage protection diode |
46L |
| W18 |
Left front seat crossmember ground point |
34E |
| W18 |
Left front seat crossmember ground point |
35E |
| W18 |
Left front seat crossmember ground point |
42L |
| W18 |
Left front seat crossmember ground point |
50E |
| W19 |
Right front seat crossmember ground point |
34E |
| W19 |
Right front seat crossmember ground point |
35E |
| W19 |
Right front seat crossmember ground point |
42L |
| W26 |
Supplemental restraint system (SRS) control unit ground point |
20E |
| W7 |
Right wheelhouse trunk ground point |
51E |
| X150/1 |
Driver NECK-PRO head restraint electrical connector |
56H |
| X150/1 |
Driver NECK-PRO head restraint electrical connector |
58H |
| X150/2 |
Front passenger NECK-PRO head restraint electrical connector |
44H |
| X150/2 |
Front passenger NECK-PRO head restraint electrical connector |
47H |
| X28/18 |
ACSR [AKSE] seat occupied recognition electrical connector |
42H |
| X28/47 |
Left rear emergency tensioning retractor squib electrical connector |
66H |
| X28/48 |
Right rear emergency tensioning retractor squib electrical connector |
68H |
| X30/30 |
Vehicle floor chassis CAN voltage distributor electrical connector |
7L |
| X35/1 |
Left front door electrical connector |
25H |
| X35/2 |
Right front door electrical connector |
27H |
| X35/3 |
Left rear door electrical connector |
77H |
| X35/4 |
Right rear door electrical connector |
78H |
| X55/3 |
Driver seat contacting strip |
34H |
| X55/3 |
Driver seat contacting strip |
58E |
| X55/4 |
Front passenger seat contacting strip |
31H |
| X55/4 |
Front passenger seat contacting strip |
42E |
| Y24/12 |
Driver seat NECK-PRO head restraint solenoid |
56L |
| Y24/13 |
Front passenger seat NECK-PRO head restraint solenoid |
45L |
| Z6/15 |
Right seat belt buckle circuit 31 connector sleeve |
31E |
| Z6/15 |
Right seat belt buckle circuit 31 connector sleeve |
36E |
