| 1 |
Circuit 15, status |
10K |
| 1 |
Circuit 15, status |
10E |
| 2 |
Seat ventilation button, status |
9J |
| 2 |
Seat ventilation button, status |
8E |
| 3 |
Seat ventilation status indication, signal |
9G |
| 3 |
Seat ventilation status indication, signal |
6C |
| 4 |
Seat ventilation, actuation |
4K |
| 4 |
Seat ventilation, actuation |
6K |
| 4 |
Seat ventilation, actuation |
4J |
| 4 |
Seat ventilation, actuation |
6J |
| A8/1 |
Transmitter key |
14F |
| CAN B |
Interior CAN |
9H |
| CAN B |
Interior CAN |
13H |
| CAN B |
Interior CAN |
11F |
| LIN 1 |
Instrument panel LIN |
7D |
| M18/10 |
Left front backrest seat ventilation motors |
3K |
| M18/11 |
Right front seat cushion seat ventilation motors |
3H |
| M18/12 |
Right front backrest seat ventilation motors |
3H |
| M18/9 |
Left front seat cushion seat ventilation motors |
3K |
| N10/1 |
Front SAM control unit with fuse and relay module |
9E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
9K |
| N29/5 |
Left front seat ventilation blower regulator |
5K |
| N29/6 |
Right front seat ventilation blower regulator |
5J |
| N72/1 |
Upper control panel control unit |
5B |
| N72/1s13 |
Left front seat ventilation button |
3A |
| N72/1s14 |
Right front seat ventilation button |
6A |
| N73 |
Electronic ignition switch control unit |
13E |
