| 1 |
Access authorization code, signal |
|
| 1 |
Access authorization code, signal |
|
| 1 |
Access authorization code, signal |
|
| 1 |
Access authorization code, signal |
|
| 1 |
Access authorization code, signal |
|
| 1 |
Access authorization code, signal |
|
| 2 |
Panic alarm, signal |
|
| 2 |
Panic alarm, signal |
|
| 2 |
Panic alarm, signal |
|
| 2 |
Panic alarm, signal |
|
| 2 |
Panic alarm, signal |
|
| 2 |
Panic alarm, signal |
|
| 3 |
Panic alarm, status |
|
| 4 |
Flasher frequency, signal |
|
| 4 |
Flasher frequency, signal |
|
| 4 |
Flasher frequency, signal |
|
| 5 |
Turn signal lamp, actuation |
|
| 5 |
Turn signal lamp, actuation |
|
| 5 |
Turn signal lamp, actuation |
|
| 5 |
Turn signal lamp, actuation |
|
| 5 |
Turn signal lamp, actuation |
|
| 5 |
Turn signal lamp, actuation |
|
| 6 |
Alarm siren, actuation |
|
| 7 |
Interior lamp, request |
|
| A2/12 |
Rear window antenna amplifier module |
|
| A8/1 |
Transmitter key |
|
| A8/1 |
Transmitter key |
|
| B58 |
Driver door infrared sensor |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| E1e5 |
Left turn signal lamp |
|
| E2e5 |
Right turn signal lamp |
|
| E3e1 |
Left turn signal lamp |
|
| E4e1 |
Right turn signal lamp |
|
| E6/5 |
Left outside mirror turn signal lamp |
|
| E6/6 |
Right outside mirror turn signal lamp |
|
| H3/1 |
Alarm signal siren |
|
| LIN B4 |
Rear SAM LIN |
|
| N10/1 |
Front SAM control unit with fuse and relay module |
|
| N10/2 |
Rear SAM control unit with fuse and relay module |
|
| N69/1 |
Left front door control unit |
|
| N69/2 |
Right front door control unit |
|
| N70 |
Overhead control panel control unit |
|
| N73 |
EIS [EZS] control unit |
|
