| 1 |
Vehicle dynamics, status |
6 J |
| 10 |
PRE-SAFE® fault, message |
12 D |
| 11 |
Circuit 15, status ON |
9 E |
| 12 |
Steering angle sensor, signal |
8 K |
| 2 |
Seat belt buckle and seat belt reminder warning switch, status |
3 E |
| 2 |
Seat belt buckle and seat belt reminder warning switch, status |
5 J |
| 3 |
PRE-SAFE® situation detected, signal |
9 G |
| 3 |
PRE-SAFE® situation detected, signal |
13 J |
| 3 |
PRE-SAFE® situation detected, signal |
17 D |
| 3 |
PRE-SAFE® situation detected, signal |
23 H |
| 3 |
PRE-SAFE® situation detected, signal |
25 D |
| 4 |
Front passenger seat occupation, status |
9 F |
| 4 |
Front passenger seat occupation, status |
12 F |
| 4 |
Front passenger seat occupation, status |
23 H |
| 5 |
Seat adjustment motors, actuation |
21 K |
| 6 |
Tilting/sliding roof motor, actuation |
17 H |
| 7 |
Power window motor, actuation |
15 B |
| 7 |
Power window motor, actuation |
23 C |
| 8 |
Manual adjustment, request |
12 J |
| 8 |
Manual adjustment, request |
18 B |
| 8 |
Manual adjustment, request |
24 K |
| 8 |
Manual adjustment, request |
26 C |
| 9 |
ESP OFF, request |
10 E |
| 9 |
ESP OFF, request |
10 H |
| A1 |
Instrument cluster |
11 B |
| A76 |
Left front reversible emergency tensioning retractor |
5 H |
| A76/1 |
Right front reversible emergency tensioning retractor |
5 H |
| A8/1 |
Transmitter key |
6 C |
| CAN B |
Interior CAN |
9 D |
| CAN B |
Interior CAN |
12 H |
| CAN B |
Interior CAN |
13 G |
| CAN B |
Interior CAN |
13 F |
| CAN B |
Interior CAN |
13 E |
| CAN B |
Interior CAN |
20 G |
| CAN B |
Interior CAN |
20 F |
| CAN C |
Engine compartment CAN |
3 J |
| CAN C |
Engine compartment CAN |
6 F |
| CAN C |
Engine compartment CAN |
6 E |
| CAN C |
Engine compartment CAN |
6 L |
| CAN C |
Engine compartment CAN |
6 G |
| CAN C |
Engine compartment CAN |
7 J |
| CAN C |
Engine compartment CAN |
9 H |
| CAN C |
Engine compartment CAN |
11 D |
| Code 242 |
Electrically adjustable front passenger seat with memory function |
18 J |
| Code 414 |
Power glass tilting/sliding sunroof |
16 J |
| M10/3 |
Left front power window motor |
14 A |
| M10/4 |
Right front power window motor |
14 B |
| M10/5 |
Left rear power window motor |
22 B |
| M10/6 |
Right rear power window motor |
22 B |
| M12 |
Tilting/sliding roof (SR [SHD]) drive unit |
17 K |
| M28/1 |
Seat fore/aft adjustment motor, front passenger |
20 K |
| M28/2 |
Rear seat height adjustment motor, front passenger |
20 K |
| M28/3 |
Front seat height adjustment motor, front passenger |
20 K |
| M28/5 |
Backrest angle adjustment motor, front passenger |
20 K |
| N10 |
Front SAM control unit |
24 B |
| N2/13 |
WSS control unit (Weight Sensing System) |
28 F |
| N2/7 |
Restraint systems control module |
2 F |
| N32/2 |
Front passenger front seat adjustment control module with memory |
22 J |
| N47-5 |
ESP control module |
9 J |
| N69/1 |
Left front door control module |
16 B |
| N69/2 |
Right front door control module |
16 B |
| N70 |
Overhead control panel control module |
12 J |
| N70s1 |
Roof switch |
11 J |
| N72/1 |
Upper control panel control module |
8 B |
| N72/1s1 |
ESP OFF switch |
8 B |
| N73 |
EIS [EZS] control unit |
5 B |
| N80 |
Steering column module |
2 K |
| N93 |
Central gateway control module |
10 E |
| S20/1 |
Power window and outside mirror adjustment switch group, driver |
18 B |
| S21/2 |
Front passenger power window switch |
18 B |
| S21/3 |
Left rear power window switch |
27 B |
| S21/4 |
Right rear power window switch |
27 C |
| S68/1 |
Driver seat belt buckle and seat belt warning switch |
2 D |
| S68/2 |
Front passenger seat belt buckle and seat belt warning switch |
2 D |
| S92 |
Front passenger seat with memory adjustment switch group |
26 J |
