| A0 |
Color code key |
80L |
| A1 |
Instrument cluster |
10L |
| A76 |
Left front reversible emergency tensioning retractor |
56L |
| A76 |
Left front reversible emergency tensioning retractor |
64L |
| A76/1 |
Right front reversible emergency tensioning retractor |
60L |
| A76/1 |
Right front reversible emergency tensioning retractor |
67L |
| A80 |
Intelligent servo module for DIRECT SELECT |
34L |
| N15/7 |
Transfer case control unit |
41L |
| N15/9 |
Rear axle differential lock control unit |
44L |
| N2/7 |
Restraint systems control unit |
53L |
| N3/10 |
ME-SFI [ME] control unit |
19L |
| N3/10 |
ME-SFI [ME] control unit |
23L |
| N3/9 |
CDI control unit |
27L |
| N47-5 |
ESP control unit |
37L |
| N51 |
AIRMATIC control unit |
49L |
| N71 |
Headlamp range adjustment control unit |
71L |
| N73 |
EIS [EZS] control unit |
15L |
| N80 |
Steering column module |
7L |
| N93 |
Central gateway control unit |
3L |
| U12 |
Valid for left-hand drive vehicles |
13F |
| U12 |
Valid for left-hand drive vehicles |
5C |
| U12 |
Valid for left-hand drive vehicles |
11C |
| U12 |
Valid for left-hand drive vehicles |
68E |
| U12 |
Valid for left-hand drive vehicles |
68D |
| U127 |
Valid for engine 272, engine 273 KE |
21E |
| U13 |
Valid for right-hand drive vehicles |
15E |
| U13 |
Valid for right-hand drive vehicles |
5C |
| U13 |
Valid for right-hand drive vehicles |
10D |
| U13 |
Valid for right-hand drive vehicles |
63E |
| U13 |
Valid for right-hand drive vehicles |
64D |
| U151 |
Valid for engine 113 |
17E |
| U151 |
Valid for engine 113 |
29C |
| U152 |
Valid for engine 156 |
21E |
| U233 |
Valid for kneebag |
15F |
| U234 |
Not valid for kneebag |
13F |
| U475 |
Valid for M 272 |
1C |
| U501 |
Valid for xenon headlamps |
70C |
| U502 |
Valid for AIRMATIC |
47A |
| U552 |
Valid for offroad package |
40A |
| U681 |
Valid for all except M113 |
29C |
| U775 |
Valid for reversible emergency tensioning retractor |
55C |
| U775 |
Valid for reversible emergency tensioning retractor |
62C |
| U880 |
Valid for engine 642 |
1C |
| U880 |
Valid for engine 642 |
25E |
| U882 |
Valid for engine 629 |
25E |
| U932 |
Valid for engine 642 BLUETEC |
25E |
| W15/1 |
Ground (right footwell) |
6E |
| W15/2 |
Ground (left footwell) |
6E |
| X18 |
Interior/cockpit connector |
9E |
| X18 |
Interior/cockpit connector |
11E |
| X22/6 |
Automatic transmission/intelligent servo module connector |
30H |
| X25/2 |
Engine compartment/interior compartment connector |
22H |
| X25/2 |
Engine compartment/interior compartment connector |
26H |
| X25/2 |
Engine compartment/interior compartment connector |
30E |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
4A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
12A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
28A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
20A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
36A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
44A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
52A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
60A |
| X30/19 |
Passenger-side voltage distributor (CAN C) connector |
68A |
| X99/18 |
EZS intermediate connector |
15H |
| Y3/8 |
Electric control unit (VGS) |
30L |
| Z35/7 |
Cockpit CAN bus node (high) |
9G |
| Z35/8 |
Cockpit CAN bus node (low) |
10G |
| Z37/71 |
Reversible emergency tensioning retractor CAN engine bus (low) connector sleeve |
57H |
| Z37/72 |
Reversible emergency tensioning retractor CAN engine bus (high) connector sleeve |
56H |
