| F4 |
Load compartment fuse and relay box |
23 A |
| N118 |
Fuel pump control unit |
15 A |
| N118/3 |
Left fuel pump control unit |
15 L |
| N118/4 |
Right fuel pump control unit |
17 L |
| N88 |
TPM [RDK] control unit |
20 A |
| R12/11 |
Left 2nd row sidebag squib |
26 A |
| R12/12 |
Right 2nd row sidebag squib |
27 A |
| R13/5 |
Left 2nd row seat heated cushion |
2 L |
| R13/5 |
Left 2nd row seat heated cushion |
9 L |
| R13/6 |
Left 2nd row backrest heated cushion |
3 L |
| R13/6 |
Left 2nd row backrest heated cushion |
11 L |
| R13/7 |
Right 2nd row seat heated cushion |
5 L |
| R13/7 |
Right 2nd row seat heated cushion |
12 L |
| R13/8 |
Right 2nd row backrest heated cushion |
6 L |
| R13/8 |
Right 2nd row backrest heated cushion |
14 L |
| U152 |
Valid for engine 156 |
15 G |
| U154 |
Valid for 164.1 |
7 F |
| U154 |
Valid for 164.1 |
25 C |
| U155 |
Valid for 164.8 |
1 F |
| U978 |
Valid for full hybrid drive |
13 A |
| W17/3 |
Ground 2 (right rear seat) |
16 D |
| X55/23 |
Left 2/3 bench seat (2nd seat row) backrest/cushion separation point |
1 J |
| X55/24 |
Right 1/3 bench seat (2nd seat row) backrest/cushion separation point |
4 J |
| X55/5 |
Left rear seat adjustment connector block |
2 E |
| X55/5 |
Left rear seat adjustment connector block |
8 G |
| X55/5 |
Left rear seat adjustment connector block |
10 G |
| X55/5 |
Left rear seat adjustment connector block |
25 H |
| X55/6 |
Right rear seat adjustment connector block |
4 E |
| X55/6 |
Right rear seat adjustment connector block |
11 G |
| X55/6 |
Right rear seat adjustment connector block |
13 G |
| X55/6 |
Right rear seat adjustment connector block |
27 H |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
19 L |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
25 L |
| Z61/12 |
Left circuit 31 2nd seat row solder point |
2 G |
| Z61/13 |
Right circuit 31 2nd seat row solder point |
4 G |
