| A17/1 |
Left front KEYLESS GO door handle |
50 L |
| A17/1x1 |
Left front KEYLESS-GO door handle connector |
50 K |
| A17/2 |
Right front KEYLESS GO door handle |
52 L |
| A17/2x1 |
Right front KEYLESS-GO door handle connector |
51 K |
| A17/3 |
Left rear KEYLESS GO door handle |
54 L |
| A17/3x1 |
Left rear KEYLESS-GO door handle connector |
53 K |
| A17/4 |
Right rear KEYLESS GO door handle |
57 L |
| A17/4x1 |
Right rear KEYLESS-GO door handle connector |
57 K |
| A2/35 |
Trunk KEYLESS GO antenna |
60 L |
| A2/39 |
Left rear door KEYLESS-GO antenna |
55 L |
| A2/41 |
Right rear door KEYLESS-GO antenna |
58 L |
| A2/60 |
Cockpit KEYLESS-GO antenna |
48 L |
| A2/61 |
Interior KEYLESS GO antenna |
45 L |
| A2/93 |
Roof antenna module |
65 L |
| F4 |
Load compartment fuse and relay box |
3 L |
| F4f33 |
Fuse 33 |
2 L |
| M14/5 |
Right front door CL [ZV] motor |
38 L |
| M14/6 |
Left front door CL [ZV] motor |
33 L |
| M14/8 |
Left rear door CL [ZV] motor |
8 L |
| M14/9 |
Right rear door CL [ZV] motor |
28 L |
| N10 |
Front SAM control unit |
14 L |
| N10/8 |
Rear SAM control unit |
18 L |
| N69/5 |
KEYLESS-GO control unit |
4 A |
| N69/5 |
KEYLESS-GO control unit |
12 A |
| N69/5 |
KEYLESS-GO control unit |
20 A |
| N69/5 |
KEYLESS-GO control unit |
28 A |
| N69/5 |
KEYLESS-GO control unit |
36 A |
| N69/5 |
KEYLESS-GO control unit |
44 A |
| N69/5 |
KEYLESS-GO control unit |
53 A |
| N69/5 |
KEYLESS-GO control unit |
61 A |
| S62/21 |
Rear-end door KEYLESS-GO button |
62 L |
| U154 |
Valid for 164.1 |
22 H |
| U154 |
Valid for 164.1 |
40 G |
| U155 |
Valid for 164.8 |
22 H |
| U155 |
Valid for 164.8 |
40 G |
| W17 |
Ground (right rear seat) |
21 L |
| W29/9 |
Ground (right D-pillar) |
63 L |
| W7/7 |
Ground (right spare tire well) |
3 E |
| W8 |
Ground (rear-end door) |
62 H |
| W8/2 |
Ground (right rear-end door) |
63 H |
| X18 |
Interior/cockpit connector |
48 E |
| X30/4 |
Right voltage distributor (CAN) connector |
42 L |
| X30/5 |
Left voltage distributor (CAN) connector |
42 L |
| X35/1 |
Left front door separation point |
30 H |
| X35/1 |
Left front door separation point |
50 E |
| X35/2 |
Right front door separation point |
35 H |
| X35/2 |
Right front door separation point |
51 E |
| X35/3 |
Left rear door separation point |
5 G |
| X35/3 |
Left rear door separation point |
53 E |
| X35/4 |
Right rear door separation point |
25 G |
| X35/4 |
Right rear door separation point |
56 E |
| X8/34 |
Left front door handle connector |
50 H |
| X8/35 |
Right front door handle connector |
51 H |
| X8/36 |
Left rear door handle connector |
53 H |
| X8/37 |
Right rear door handle connector |
56 H |
| Z204/3 |
Circuit 31 right rear seat voltage distributor connector |
23 L |
| Z204/4 |
Circuit 31 right footwell voltage distributor connector |
23 L |
| Z204/5 |
Circuit 31 left footwell voltage distributor connector (1) |
11 L |
| Z204/7 |
Circuit 31 left footwell voltage distributor connector (2) |
11 L |
| Z6/12 |
Left rear door ground connector sleeve |
9 H |
| Z6/13 |
Right rear door ground connector sleeve |
25 H |
