| A28/3 |
E-net compensator |
8 L |
| A28/3x1 |
E-net compensator connector |
9 J |
| A34/15 |
UHI portable CTEL holder (Universal Handy Interface) |
13 L |
| A34/15x1 |
Connector 1, UPCI [UHI] portable CTEL holder (Universal Handy Interface) |
12 K |
| A34/15x2 |
Connector 2, UPCI [UHI] portable CTEL holder (Universal Handy Interface) |
10 K |
| A67b1 |
Hands-free system microphone group |
19 L |
| A67b1x1 |
Hands-free system microphone group connector |
18 J |
| F4 |
Load compartment fuse and relay box |
3 L |
| F4f23 |
Fuse 23 |
2 L |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
4 A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
12 A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
20 A |
| N123/1 |
Universal Portable CTEL Interface (UPCI [UHI]) control unit |
27 A |
| N123/4 |
Emergency call system control unit |
26 L |
| U904 |
Wiring harness installed but nonfunctional |
7 F |
| W17/1 |
Ground (left rear seat) |
5 H |
| X18/2 |
Interior/roof connector |
18 E |
| X29/6 |
Center console intermediate connector |
10 H |
| X29/6 |
Center console intermediate connector |
12 H |
| X29/6 |
Center console intermediate connector |
13 F |
| X39/70 |
FFS [RBA} microphone array connector |
22 E |
| Z204/6 |
Circuit 31 left rear seat voltage distributor connector |
5 L |
| Z53/25 |
UPCI [UHI] circuit 30 interior compartment solder point |
1 E |
| Z53/26 |
Telematics circuit 31 interior solder point 1 |
7 E |
