| 1 |
Door rotary tumbler switch, status |
17L |
| 1 |
Door rotary tumbler switch, status |
7F |
| 1 |
Door rotary tumbler switch, status |
19D |
| 10 |
AIRMATIC compressor, actuation |
22B |
| 10 |
AIRMATIC compressor, actuation |
20C |
| 11 |
AIRMATIC central reservoir charge valve, actuation |
26E |
| 12 |
AIRMATIC pressure reduction valve, actuation |
22B |
| 13 |
Wheel speed, signal |
21F |
| 14 |
Level control switch, status |
7C |
| 14 |
Level control switch, status |
18D |
| 15 |
Level control switch (LED), actuation |
7B |
| 15 |
Level control switch (LED), actuation |
8D |
| 16 |
Steering angle, signal |
25J |
| 16 |
Steering angle, signal |
22F |
| 17 |
Service brake, status |
21G |
| 18 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
21G |
| 19 |
AIRMATIC fault, message |
10G |
| 2 |
Rear-end door locking unit, status |
16L |
| 2 |
Rear-end door locking unit, status |
7F |
| 2 |
Rear-end door locking unit, status |
18D |
| 20 |
Trailer operation detected, signal |
8G |
| 20 |
Trailer operation detected, signal |
17D |
| 3 |
Activate system, signal |
20F |
| 4 |
Level sensor, status |
22E |
| 5 |
AIRMATIC pressure sensor, signal |
22E |
| 6 |
Level control valve, actuation |
26E |
| 7 |
Engine speed, signal |
19F |
| 8 |
Outside air pressure/temperature, signal |
19F |
| 9 |
Outside temperature indicator temperature sensor, signal |
9D |
| 9 |
Outside temperature indicator temperature sensor, signal |
18D |
| A1 |
Instrument cluster |
10H |
| A9/1 |
AIRMATIC compressor unit |
24B |
| B22/10 |
Right rear level sensor |
26H |
| B22/7 |
Left rear level sensor |
26G |
| B22/8 |
Left front level sensor |
26G |
| B22/9 |
Right front level sensor |
26G |
| CAN B |
Interior CAN |
4D |
| CAN B |
Interior CAN |
7B |
| CAN B |
Interior CAN |
7G |
| CAN B |
Interior CAN |
12K |
| CAN C |
Engine compartment CAN |
12E |
| CAN C |
Engine compartment CAN |
12E |
| CAN C |
Engine compartment CAN |
15F |
| CAN C |
Engine compartment CAN |
18E |
| CAN C |
Engine compartment CAN |
18F |
| CAN C |
Engine compartment CAN |
21G |
| F58kG |
Air suspension compressor |
20B |
| N10 |
Front SAM control unit |
18J |
| N10/8 |
Rear SAM control unit |
7K |
| N22 |
AAC [KLA] control and operating unit |
2D |
| N22/7 |
Comfort AAC [KLA] control and operating unit |
2D |
| N3/10 |
ME-SFI [ME] control unit |
16G |
| N3/9 |
CDI control unit |
13G |
| N47-5 |
ESP control unit |
21H |
| N49 |
Steering angle sensor |
27J |
| N51 |
AIRMATIC control unit |
21D |
| N72/1 |
Upper control panel control unit |
7A |
| N80 |
Steering column module |
24J |
| N93 |
Central gateway control unit |
7D |
| U29 |
Valid for AAC [KLA] |
1C |
| U673 |
Valid for comfort AAC [K-KLA] |
1D |
| U74 |
Valid for diesel engines |
11F |
| U75 |
Valid for gasoline engines |
14F |
| Y36 |
AIRmatic valve unit |
26E |
