Wiring diagram of outside mirrors - PE88.79-P-2000-99CAB
| Code: | Designation: | Position: |
|---|---|---|
| A0 | Explanation of color codes | 15 L |
| E6/6 | Right exterior mirror turn signal lamp | 1 L |
| M21/2 | Right electrically adjustable and heated exterior mirror | 4 L |
| M21/2e1 | Right outside mirror ambient lamp | 7 L |
| M21/2m1 | Mirror up/down adjustment motor | 4 J |
| M21/2m2 | Mirror in/out adjustment motor | 4 K |
| M21/2m3 | Mirror fold-in motor | 8 L |
| M21/2r1 | Mirror heater | 3 L |
| M21/2r2 | Mirror up/down adjustment potentiometer | 6 J |
| M21/2r3 | Mirror in/out adjustment potentiometer | 6 K |
| N69/2 | Right door control module | 4 A |
