Fuse and relay box, as-built configuration - GF54.15-P-0800SX
MODEL 221.0 /1, 216.3 up to Model Year 8
Shown on model 221
Illustrated on model 221
| Fuse assignment of fuse and relay box in left engine compartment | GF54.15-P-1256-03SX |
| Relay assignment of fuse and relay box in left side of engine compartment | GF54.15-P-1257-03SX |
| Fuse assignment of fuse and relay box in trunk | GF54.15-P-1256-06SX |
| Relay assignment of fuse and relay box in trunk | GF54.15-P-1257-04SX |
| Fuse assignment of front prefuse box | GF54.15-P-1256-07SX |
| Fuse assignment of fuse box in right of cockpit | GF54.15-P-1256-12SX |
| Fuse assignment of fuse box in left of cockpit | GF54.15-P-1256-13SX |
| Fuse assignment of the vehicle power supply control unit | GF54.15-P-1256-17SX |
