| Code
: |
Designation
: |
Position
: |
| A0 |
Color code key |
48H |
| A2/30 |
Navigation processor |
13L |
| E18/4 |
Right luggage compartment lamp |
27K |
| E18/5 |
Left luggage compartment lamp |
28K |
| E19/1 |
Left license plate lamp |
34K |
| E19/2 |
Right license plate lamp |
35K |
| E3 |
Left taillamp |
23K |
| E4 |
Right taillamp |
26K |
| E40/2 |
Left trunk lid ambient and warning lamp |
33K |
| E40/3 |
Right trunk lid ambient and warning lamp |
34K |
| F32/4 |
Interior prefuse box |
3L |
| M14/10 |
Fuel filler flap CL [ZV] motor |
28K |
| M14/7 |
Trunk lid CL [ZV] motor |
31K |
| N10/2 |
Rear SAM control unit with fuse and relay module |
5A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
12A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
28A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
20A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
43A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
36A |
| N10/2f137 |
Fuse 137 |
15C |
| N10/2f138 |
Fuse 138 |
9C |
| N10/2kM |
Circuit 15 (2)/spare 1 relay (changeover contact) |
2A |
| N10/2kN |
Circuit 15R relay |
6A |
| N123/4 |
Emergency call system control unit |
7L |
| N66/10 |
Backup camera voltage supply module |
19L |
| N82/1 |
Vehicle power supply control unit |
3L |
| S62/21 |
Trunk lid KEYLESS-GO button |
39L |
| S88/10 |
Trunk lid emergency release switch |
43L |
| S88/6 |
Trunk lid contact switch |
41L |
| S88/8 |
Trunk lid external operation switch |
37L |
| U1 |
Valid for {{USA}} |
24G |
| U1 |
Valid for {{USA}} |
42H |
| U1 |
Valid for {{USA}} |
5E |
| U1 |
Valid for {{USA}} |
9B |
| U52 |
Valid for {{Japan}} |
9E |
| U52 |
Valid for {{Japan}} |
9B |
| U563 |
Valid for rear entertainment (DVD) |
14E |
| U777 |
Valid for navigation |
12E |
| U82 |
Valid for KEYLESS GO |
38H |
| U899 |
Valid for backup camera |
17E |
| W17 |
Ground (right rear seat) |
17G |
| W54 |
Ground (right rear wheelhouse) |
39E |
| X1/28 |
TV/tuner connector |
10L |
| X18 |
Cockpit wiring harness and FFS [RBA] connector |
13H |
| X60 |
Volume control intermediate connector |
15L |
| X60 |
Volume control intermediate connector |
16L |
| Z3/12 |
Circuit 15R connector sleeve |
10H |
| Z38 |
Backup lamp connector sleeve |
21G |
| Z4/6z5 |
Luggage compartment lamp circuit 30 connector sleeve |
33G |
| Z6/92 |
Trunk lid ground connector sleeve |
39G |
