GPS antenna, component description - GF82.62-P-4118RC
MODEL 171 with CODE (525) MB Audio 50 APS radio
MODEL 171 with CODE (511) Audio 50 APS with DVD changer
MODEL 171 with CODE (527) COMAND APS with single DVD drive (with navigation)
MODEL 171 with CODE (512) COMAND APS with DVD changer
MODEL 171 with CODE (359) TELE AID emergency call system
MODEL 171 as of model year 09/YoM 08 model refinement package
Location The GPS antenna is integrated into the inside rearview mirror unit (A67) at the top of the windshield.
Task The GPS antenna receives the signals in the microwave range from the navigation satellites and forwards the navigation signals via a direct line to the radio and navigation unit (A2/56), COMAND operating, display and controller unit (A40/3) or to the emergency call system control unit (N123/4). For code (359) TELE AID emergency call system and code (512) COMAND APS with DVD changer, the GPS antenna splitter (A2/5) is also installed between the GPS antenna and the COMAND operating, display and controller unit.
