| 1 |
Front seat belt buckle switches, status |
8E |
| 1 |
Front seat belt buckle switches, status |
13F |
| 1 |
Front seat belt buckle switches, status |
22C |
| 1 |
Front seat belt buckle switches, status |
|
| 1 |
Front seat belt buckle switches, status |
|
| 10 |
WSS (Weight Sensing System) sensor, signal |
33B |
| 11 |
Cockpit switch group, signal |
9H |
| 11 |
Cockpit switch group, signal |
|
| 11 |
Cockpit switch group, signal |
|
| 11 |
Cockpit switch group, signal |
|
| 12 |
Seat occupied recognition pressure sensor, signal |
37B |
| 13 |
Close range radar sensors, signal |
4J |
| 2 |
Front passenger seat occupation, status |
16F |
| 2 |
Front passenger seat occupation, status |
22D |
| 3 |
PRE-SAFEA® fault, message |
14E |
| 3 |
PRE-SAFEA® fault, message |
|
| 4 |
PRE-SAFEA® brake, request |
6K |
| 5 |
PRE-SAFEA® triggering, request |
13G |
| 5 |
PRE-SAFEA® triggering, request |
6B |
| 5 |
PRE-SAFEA® triggering, request |
22D |
| 5 |
PRE-SAFEA® triggering, request |
34H |
| 5 |
PRE-SAFEA® triggering, request |
25D |
| 5 |
PRE-SAFEA® triggering, request |
|
| 5 |
PRE-SAFEA® triggering, request |
|
| 5 |
PRE-SAFEA® triggering, request |
|
| 5 |
PRE-SAFEA® triggering, request |
|
| 5 |
PRE-SAFEA® triggering, request |
|
| 6 |
DTR controller unit, signal |
|
| 7 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
9J |
| 8 |
Circuit 15, status |
|
| 9 |
Rear seat belt buckle switch, status |
16F |
| 9 |
Rear seat belt buckle switch, status |
25D |
| 9 |
Rear seat belt buckle switch, status |
28B |
| A1 |
Instrument cluster |
15J |
| A76 |
Left front reversible emergency tensioning retractor |
7A |
| A76/1 |
Right front reversible emergency tensioning retractor |
7A |
| A8/1 |
Transmitter key |
14A |
| A86/1b1 |
Left outer radar sensor, front bumper |
2A |
| A86/1b2 |
Left inner radar sensor, front bumper |
2B |
| A86/1b3 |
Right inner radar sensor, front bumper |
2B |
| A86/1b4 |
Right outer radar sensor, front bumper |
2B |
| A89 |
DTR control unit |
2E |
| B24/15 |
Yaw rate, lateral and longitudinal acceleration sensor |
11J |
| B48/11 |
Left front WSS (Weight Sensing System) sensor |
35A |
| B48/12 |
Right front WSS (Weight Sensing System) sensor |
35B |
| B48/13 |
Left rear WSS (Weight Sensing System) sensor |
35B |
| B48/14 |
Right rear WSS (Weight Sensing System) sensor |
35B |
| B48/4 |
Seat occupied recognition pressure sensor |
39B |
| CAN B |
Interior CAN |
20G |
| CAN B |
Interior CAN |
20G |
| CAN B |
Interior CAN |
20E |
| CAN B |
Interior CAN |
20E |
| CAN B |
Interior CAN |
20F |
| CAN B |
Interior CAN |
14D |
| CAN B |
Interior CAN |
28G |
| CAN B |
Interior CAN |
28G |
| CAN B |
Interior CAN |
28F |
| CAN B |
Interior CAN |
16D |
| CAN E |
Chassis CAN |
11F |
| CAN E |
Chassis CAN |
7H |
| CAN E |
Chassis CAN |
5K |
| CAN E |
Chassis CAN |
11G |
| CAN E |
Chassis CAN |
7D |
| CAN E |
Chassis CAN |
5F |
| CAN E |
Chassis CAN |
11C |
| CAN F |
Central CAN |
15H |
| CAN F |
Central CAN |
14H |
| CAN H |
Vehicle dynamics CAN |
2H |
| CAN H |
Vehicle dynamics CAN |
10K |
| CAN I |
Drive train sensor CAN |
4F |
| Code 223 |
Rear bench seat with electrically adjustable outer seats with PRE-SAFE positioning function for outer seats and outer head restraints |
23A |
| Code 233 |
DISTRONIC PLUS |
1E |
| Code 406 |
Multicontour seats in rear |
32J |
| Code 409 |
Left and right front multicontour seats |
26J |
| Code 432 |
Left and right front dynamic multicontour seats |
29J |
| Code 494 |
USA version |
31A |
| Code 494 |
USA version |
36A |
| LIN 1 |
Instrument panel LIN |
19B |
| N10/2 |
Rear SAM control unit with fuse and relay module |
30A |
| N110 |
Weight Sensing System (WSS) control unit |
36B |
| N2/13 |
WSS (Weight Sensing System) control unit |
32B |
| N2/7 |
Restraint systems control unit |
7E |
| N25/6 |
Rear seats control unit |
24B |
| N32/15 |
Left front multicontour backrest control unit |
27J |
| N32/16 |
Right front multicontour backrest control unit |
27J |
| N32/19 |
Left front dynamic seat control unit |
30J |
| N32/2 |
Right front seat control unit |
21A |
| N32/20 |
Left rear multicontour backrest control unit |
34J |
| N32/21 |
Right rear multicontour backrest control unit |
34J |
| N32/22 |
Right front dynamic seat control unit |
30J |
| N47-5 |
ESP control unit |
7J |
| N62/1 |
Radar sensors control unit (SGR) |
2J |
| N69/1 |
Left front door control unit |
18J |
| N69/2 |
Right front door control unit |
21J |
| N69/3 |
Rear left door control unit |
18J |
| N69/4 |
Right rear door control unit |
21J |
| N70 |
Overhead control panel control unit |
24J |
| N72/1 |
Upper control panel control unit |
17A |
| N73 |
EIS [EZS] control unit |
13A |
| N93 |
Central gateway control unit |
15E |
| S6/2 |
Cockpit switch group |
19C |
| S6/2s11 |
ESP OFF switch |
19C |
| S68/1 |
Driver seat belt buckle and seat belt warning switch |
9D |
| S68/11 |
Left rear seat belt buckle switch |
27B |
| S68/12 |
Right rear seat belt buckle switch |
27B |
| S68/2 |
Front passenger seat belt buckle and seat belt warning switch |
9D |
