Information on applying sealant to cylinder head gasket - AH01.30-P-1000-04RX
WARNING: This page does not describe the selected car, but rather 28 other vehicles, including the 2012 Mercedes-Benz GL550, 2012 Mercedes-Benz GL450, 2011 Mercedes-Benz ML63, 2011 Mercedes-Benz ML550, and 2011 Mercedes-Benz ML350. However, it is still accessible from the selected car via links, so may be relevant.
Engine 272, 273
Before mounting the cylinder heads, apply sealant around the timing case cover on the cylinder crankcase.
The sealing surface must be cleaned. Sealant should be applied only to the specified surface, in the form of a bead 2.0 mm (0.5 mm) in height and width (see picture).
The sealant remains workable for 10 min.
The bead should not be spread.
