Remove/install guide wheel for timing chain - AR05.10-P-7760A (ML550, GL450, GL550)
WARNING: This page does not describe the selected car, but rather 28 other vehicles, including the 2012 Mercedes-Benz GL550, 2012 Mercedes-Benz GL450, 2011 Mercedes-Benz ML63, 2011 Mercedes-Benz ML550, and 2011 Mercedes-Benz ML350. However, it is still accessible from the selected car via links, so may be relevant.
ENGINES 273
| Figure item, etc. | Work instructions | ||
| Remove/install timing case cover | AR01.40-P-8000GZA | ||
| 1 | Screw | ||
| *BA05.10-P-1006-01B |
TIMING CHAIN, CHAIN TENSIONER
| Number | Designation | Engine 273 | |
|---|---|---|---|
| BA05.10-P-1006-01B | Guide pulley to crankcase | Nm | 55 |
