| 1 |
Front seat belt buckle switches, status |
9D |
| 1 |
Front seat belt buckle switches, status |
14E |
| 1 |
Front seat belt buckle switches, status |
20C |
| 1 |
Front seat belt buckle switches, |
10H |
| 2 |
Front passenger seat occupation, status |
20D |
| 3 |
PRE-SAFE® fault, message |
14F |
| 3 |
PRE-SAFE® fault, message |
16H |
| 4 |
PRE-SAFE® brake, request |
8J |
| 5 |
PRE-SAFE® triggering, request |
13F |
| 5 |
PRE-SAFE® triggering, request |
21H |
| 5 |
PRE-SAFE® triggering, request |
19H |
| 5 |
PRE-SAFE® triggering, request |
31H |
| 5 |
PRE-SAFE® triggering, request |
20D |
| 5 |
PRE-SAFE® triggering, request |
24H |
| 5 |
PRE-SAFE® triggering, request |
27H |
| 6 |
DTR controller unit, signal |
6E |
| 7 |
Circuit 15, status |
16D |
| 8 |
Active brake intervention, request |
8K |
| 9 |
Close range radar sensors, signal |
4E |
| 9 |
Close range radar sensors, signal |
3K |
| A1 |
Instrument cluster |
15J |
| A86/1b2 |
Left inner radar sensor, front bumper |
2C |
| A86/1b2 |
Left inner radar sensor, front bumper |
3H |
| A86/1b3 |
Right inner radar sensor, front bumper |
2D |
| A86/1b3 |
Right inner radar sensor, front bumper |
3J |
| A89 |
DTR control unit |
5B |
| CAN B |
Interior CAN |
15D |
| CAN B |
Interior CAN |
19G |
| CAN B |
Interior CAN |
28G |
| CAN B |
Interior CAN |
18E |
| CAN E |
Chassis CAN |
6J |
| CAN E |
Chassis CAN |
12F |
| CAN E |
Chassis CAN |
9G |
| CAN E |
Chassis CAN |
12E |
| CAN E |
Chassis CAN |
6K |
| CAN F |
Central CAN |
15H |
| CAN H |
Vehicle dynamics CAN |
5D |
| CAN S |
Sensor CAN |
3F |
| CAN S |
Sensor CAN |
2K |
| Code 233 |
DISTRONIC PLUS |
1B |
| Code 233 |
DISTRONIC PLUS |
1H |
| Code 237 |
Active Blind Spot Assist |
1H |
| Code 238 |
Active Lane Keeping Assist |
1H |
| Code 409 |
Left and right front multicontour seats |
25H |
| Code 432 |
Left and right front dynamic multicontour seats |
29H |
| N2/7 |
Restraint systems control unit |
9E |
| N32/15 |
Left front multicontour backrest control unit |
27J |
| N32/16 |
Right front multicontour backrest control |
27J |
| N32/19 |
Left front dynamic seat control unit |
30J |
| N32/2 |
Right front seat control unit |
19A |
| N32/22 |
Right front dynamic seat control unit |
30J |
| N47-5 |
ESP control unit |
9J |
| N62/1 |
Radar sensors control unit (SGR) |
5E |
| N62/2 |
Video and radar sensor system control unit |
4K |
| N69/1 |
Left door control unit |
18J |
| N69/2 |
Right door control unit |
21J |
| N70 |
Overhead control panel control unit |
24H |
| N73 |
EIS [EZS] control unit |
15A |
| N93 |
Central gateway control unit |
15E |
| S68/1 |
Driver seat belt buckle and seat belt warning switch |
9C |
| S68/2 |
Front passenger seat belt buckle and seat belt warning switch |
9C |
